FAIRING (MODEL J 9RD) for Suzuki GSX-F 1100 1992
(1)
(1)  94400-48B40-9RD
BODY ASSY,COWLING
BODY ASSY, COWLING (BLUE/RED)
(2)
(2)  68180-48B10-9RL
68180-48B10-9RL
TAPE SET
(3)
(3)  68181-48B01-2CG
EMBLEM
EMBLEM (SPS)
(4)
(4)  68271-34A00-38Z
EMBLEM
.EMBLEM, REAR (GOLD)
(5)
(5)  94510-48B21-000
BRACE
(6)
(6)  94611-48B40-000
WIND SCREEN
(7)
(7)  94631-48B10-000
(8)
(8)  09103-10195-000
BOLT
BOLT, BRACE FRONT
(9)
(9)  07130-0816A-000
BOLT
BOLT, BRACE REAR
(10)
(10)  09139-06028-000
SCREW
SCREW, BODY REAR
(11)
(11)  09160-06056-000
WASHER
(12)
(12)  09180-06262-000
SPACER
SPACER (6.4X9X8.5)
(13)
(13)  09320-09016-000
CUSHION
(14)
(14)  09139-06030-000
SCREW
SCREW, LOWER
(15)
(15)  02142-06127-000
SCREW
SCREW, SET
(16)
(16)  94700-48B10-38T
PANEL ASSY RH
PANEL ASSY, RH (GRAY)
(17)
(17)  02142-0508A-000
SCREW CASE
.SCREW
(18)
(18)  94635-19C00-000
MOULDING
.MOLDING REFER TO FIG.56A(J- 5) FOR MOD REFER TO FIG.56B(J- 7) FOR MOD REFER TO FIG.56C(J- 9) FOR MOD REFER TO FIG.56D(J-11) FOR MOD
(19)
(19)  94800-48B10-38T
PANEL ASSY, LH (GRAY)
(20)
(20)  02142-0508A-000
SCREW CASE
.SCREW
(21)
(21)  94635-19C00-000
MOULDING
.MOLDING REFER TO FIG.56A(J- 5) FOR MOD REFER TO FIG.56B(J- 7) FOR MOD REFER TO FIG.56C(J- 9) FOR MOD REFER TO FIG.56D(J-11) FOR MOD
(22)
(22)  02142-0512A-000
SCREW
SCREW, CENTER PANEL (5X12)
(23)
(23)  09148-05020-000
NUT
(24)
(24)  03241-0512A-000
SCREW
SCREW, PANEL REAR (5X12)
(25)
(25)  09148-05020-000
NUT
(26)
(26)  09403-18406-000
REORDER ROBINSONS
CLAMP
(27)
(27)  94426-48B10-000
CAP
CAP, RH
(28)
(28)  94427-48B10-000
CAP
CAP, LH
(29)
(29)  94591-48B10-000
MOULDING
MOLDING, PANEL RH
(30)
(30)  94592-48B10-000
MOLDING, PANEL LH
(31)
(31)  94635-19C00-000
MOULDING
MOLDING, FRONT
(32)
(32)  94439-48B00-000
MOULDING
MOLDING, SIDE
(33)
(33)  94651-48B00-000
COVER
(34)
(34)  94479-48B00-000
MOULDING
MOLDING (L:325)
(35)
(35)  94470-48B00-000
COVER COMP,COWL LOWER,R
COVER ASSY, LOWER RH (BLUE/RED)
(36)
(36)  68111-00A50-764
EMBLEM
(37)
(37)  68685-48B10-9RL
TAPE, RH
(38)
(38)  94479-48B00-000
MOULDING
.MOLDING (L:210)
(39)
(39)  94480-48B00-000
COVER COMP,COWL LOWER,L
COVER ASSY, LOWER LH (BLUE/RED)
(40)
(40)  68111-00A50-764
EMBLEM
(41)
(41)  68695-48B10-9RL
TAPE, LH
(42)
(42)  94479-48B00-000
MOULDING
.MOLDING (L:210)
(43)
(43)  94475-48B00-24V
REORDER ROBINSONS
COVER, LOWER FRONT (BLUE)
(44)
(44)  09139-05025-000
SCREW
(45)
(45)  08316-2005A-000
NUT
NUT REFER TO FIG.26A(E-9) FOR MODE
(46)
(46)  94490-06B00-000
BRACE
BRACE, LOWER
(47)
(47)  94493-06B00-000
BRACE
BRACE, LOWER REAR
(48)
(48)  09139-06027-000
SCREW
SCREW, FRONT
(49)
(49)  09139-06039-000
SCREW
SCREW, R & L
(50)
(50)  94580-48B11-000
BRACE
BRACE, LOWER RH
(51)
(51)  94590-48B11-000
BRACE
BRACE, LOWER LH
(52)
(52)  01500-08127-000
BOLT
BOLT 8 X 12
(53)
(53)  08321-01087-000
LOCK WASHER
.8MM LOCK WASHER, RH
(54)
(54)  09139-06028-000
SCREW
SCREW, UPPER REAR
(55)
(55)  09139-06030-000
SCREW
(56)
(56)  09161-07006-000
WASHER
(57)
(57)  09139-06028-000
SCREW
(58)
(58)  09160-06056-000
WASHER
(59)
(59)  09180-06121-000
SPACER
(60)
(60)  09320-09016-000
CUSHION
(61)
(61)  68922-14F01-000
LABEL WARNING SCREEN
LABEL, WARNING SCREEN (ENGLISH)
Part information
(61)  68922-14F31-000
LABEL SCREEN
LABEL, SCREEN (FRENCH) REFER TO FIG.56A(J- 5) FOR MOD REFER TO FIG.56B(J- 7) FOR MOD REFER TO FIG.56C(J- 9) FOR MOD REFER TO FIG.56D(J-11) FOR MOD
Part information
Part number Description
# 1
BODY ASSY, COWLING
BODY ASSY, COWLING (BLUE/RED)
# 2
68180-48B10-9RL
68180-48B10-9RL
TAPE SET
Not available
# 3
68181-48B00-2CG
68181-48B01-2CG
EMBLEM
EMBLEM (SPS)
# 4
68271-34A00-764
EMBLEM
.EMBLEM, REAR (GOLD)
Not available
# 5
94510-48B11-000
BRACE Not available
# 6
94611-48B30-000
WIND SCREEN Not available
# 7
94631-48B10-000
MOLDING Not available
# 8
BOLT
BOLT, BRACE FRONT
# 9
07110-08165-000
07130-0816A-000
BOLT
BOLT, BRACE REAR
# 10
SCREW
SCREW, BODY REAR
# 11
WASHER
# 12
09180-06152-000
09180-06262-000
SPACER
SPACER (6.4X9X8.5)
# 13
CUSHION
# 14
SCREW
SCREW, LOWER
# 15
SCREW
SCREW, SET
# 16
PANEL ASSY RH
PANEL ASSY, RH (GRAY)
# 17
02142-05084-000
02142-0508A-000
SCREW CASE
.SCREW
# 18
94419-48B10-000
94635-19C00-000
MOULDING
.MOLDING REFER TO FIG.56A(J- 5) FOR MOD REFER TO FIG.56B(J- 7) FOR MOD REFER TO FIG.56C(J- 9) FOR MOD REFER TO FIG.56D(J-11) FOR MOD
# 19
94800-48B10-38T
PANEL ASSY, LH (GRAY) Not available
# 20
02142-05084-000
02142-0508A-000
SCREW CASE
.SCREW
# 21
94419-48B10-000
94635-19C00-000
MOULDING
.MOLDING REFER TO FIG.56A(J- 5) FOR MOD REFER TO FIG.56B(J- 7) FOR MOD REFER TO FIG.56C(J- 9) FOR MOD REFER TO FIG.56D(J-11) FOR MOD
# 22
02142-05124-000
02142-0512A-000
SCREW
SCREW, CENTER PANEL (5X12)
# 23
NUT
# 24
03242-05124-000
03241-0512A-000
SCREW
SCREW, PANEL REAR (5X12)
# 25
NUT
# 26
REORDER ROBINSONS
CLAMP
# 27
CAP
CAP, RH
# 28
CAP
CAP, LH
# 29
94591-48B10-000
MOULDING
MOLDING, PANEL RH
Not available
# 30
94592-48B10-000
MOLDING, PANEL LH Not available
# 31
94419-48B00-000
94635-19C00-000
MOULDING
MOLDING, FRONT
# 32
MOULDING
MOLDING, SIDE
# 33
94651-48B00-000
COVER Not available
# 34
MOULDING
MOLDING (L:325)
# 35
97600-48B32-9RD
COVER COMP, COWL LOWER, R
COVER ASSY, LOWER RH (BLUE/RED)
Not available
# 36
68111-00A50-764
EMBLEM Not available
# 37
68685-48B10-9RL
TAPE, RH Not available
# 38
94479-48B10-000
94479-48B00-000
MOULDING
.MOLDING (L:210)
# 39
97700-48B32-9RD
COVER COMP, COWL LOWER, L
COVER ASSY, LOWER LH (BLUE/RED)
Not available
# 40
68111-00A50-764
EMBLEM Not available
# 41
68695-48B10-9RL
TAPE, LH Not available
# 42
94479-48B10-000
94479-48B00-000
MOULDING
.MOLDING (L:210)
# 43
94475-48B00-24V
REORDER ROBINSONS
COVER, LOWER FRONT (BLUE)
Not available
# 44
SCREW
# 45
08316-26055-000
08316-2005A-000
NUT
NUT REFER TO FIG.26A(E-9) FOR MODE
# 46
BRACE
BRACE, LOWER
# 47
BRACE
BRACE, LOWER REAR
# 48
SCREW
SCREW, FRONT
# 49
SCREW
SCREW, R & L
# 50
94580-48B11-000
BRACE
BRACE, LOWER RH
Not available
# 51
94590-48B11-000
BRACE
BRACE, LOWER LH
Not available
# 52
01107-08127-000
01500-08127-000
BOLT
BOLT 8 X 12
# 53
08321-21088-000
08321-01087-000
LOCK WASHER
.8MM LOCK WASHER, RH
# 54
SCREW
SCREW, UPPER REAR
# 55
SCREW
# 56
09161-07005-000
09161-07006-000
WASHER
# 57
SCREW
# 58
WASHER
# 59
SPACER
# 60
CUSHION
# 61
68612-48B00-000
68922-14F01-000
LABEL WARNING SCREEN
LABEL, WARNING SCREEN (ENGLISH)
# 61
68612-48B10-000
68922-14F31-000
LABEL SCREEN
LABEL, SCREEN (FRENCH) REFER TO FIG.56A(J- 5) FOR MOD REFER TO FIG.56B(J- 7) FOR MOD REFER TO FIG.56C(J- 9) FOR MOD REFER TO FIG.56D(J-11) FOR MOD
Here are all the parts relating to the FAIRING (MODEL J 9RD) of your GSX-F 1992. These are all genuine parts to assure you the best possible repair which will last.
