HEADLIGHT (E18,MODEL G / H E34) REFER TO FIG.26A (E-13) FOR MODEL J E34

HEADLIGHT (MODEL J E34) FOR SUZUKI GSX-R 1100 1988

INDICATORS (E1,E6,E24) REFER TO FIG.28 (F-3) FOR E2,E4,E15,E16,E17,E18,E21,E22,

HEADLAMP ASSY

35100-07B20-999 3510007B20999

Not available

UNIT

35121-07B00-000 3512107B00000

Not available

RING, RETAINING LH

35126-27A00-000 3512627A00000

Not available

RING, RETAINING RH

35127-27A00-000 3512727A00000

Not available

SUZUKI PART
SPRING, SUPPORT

35128-46720-000 3512846720000

Not available

BEARING
BEARING, SPHERICAL

35162-04A00-000 3516204A00000

£2,95

Unit Price Incl. Tax

COVER, SOCKET

35173-48540-000 3517348540000

Not available

CORD ASSY

35171-36650-000 3517136650000

Not available

SOCKET

36118-33670-000 3611833670000

Not available

SCREW
SCREW, ADJUSTING

35153-04A00-000 3515304A00000

Not available

SPRING

35154-07B20-000 3515407B20000

Not available

H L ADJUSTING NUT
NUT

35152-27A00-000 3515227A00000

Not available

SCREW

35151-04A00-000

35151-45900-000

£6,50

Unit Price Incl. Tax

NUT

35155-04A00-000 3515504A00000

Not available

SCREW CAP
CAP, SCREW

35158-43400-000 3515843400000

£2,95

Unit Price Incl. Tax

HOUSING
HOSING

35240-06B00-000 3524006B00000

Not available

SUZUKI PART
GASKET

35242-27A00-000 3524227A00000

Not available

CLAMP (L 80)

09404-05401-000

09404-06429-000

£3,52

Unit Price Incl. Tax

BULB 12V 35/35W (B20D)
BULB (12V, 35/35W)

09471-12020-000 0947112020000

£17,69

Unit Price Incl. Tax

BULB (12V, 3W)

09471-12051-000 0947112051000

Not available

SCREW

02112-06166-000

02112-06163-000

£2,03

Unit Price Incl. Tax

SCREW CENTER SHAFT

02112-06106-000

Not available

LOCK WASHER

08321-21066-000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
