CHAIN GUARD

FRONT FORK FOR SUZUKI MARAUDER 125 2011

STEERING COLUMN

(1) 51103-12FD0-000

RH FRONT FORK DAMPER ASSY
DAMPER ASSY, FRONT FORK RH

(2) 51130-12FD0-000

TUBE INNER
.TUBE, OUTER RH

(3) 51167-03B30-000

.BUSH, GUIDE

(4) 51168-38A00-000

SPACER
.SPACER, SEAL

(5) 51153-03B30-000

SEAL OIL FORK
.SEAL, OIL

(6) 51156-03B30-000

.RING, STOPPER

(7) 51173-25D00-000

DUST SEAL
.SEAL, DUST

(8) 51195-25D00-000

OIL LOCK PIECE
.PIECE, OIL LOCK

(9) 51147-06F10-000

.BOLT

(10) 51148-36011-000

.GASKET

(11) 51110-12FD0-000

.TUBE, INNER

(12) 51121-12FA0-000

.BUSH, SLIDE

(13) 51146-12FA0-000

.PIPE, SEAT

(14) 51177-12FA0-000

.SPRING, REBOUND

(15) 51196-12FA0-000

.RING, PISTON

(16) 51171-12FD0-000

SPRING,FR
.SPRING, FRONT

(17) 51192-12FA0-000

.JOINT, SPRING

(18) 51176-25D00-000

SPRING SPACER
.COLLAR, SPRING

(19) 51117-25D00-000

.O RING

(20) 51189-12FA0-000

.BOLT, FORK

(21) 51166-12FA0-000

.BOLT, RH (8X35)

(22) 51104-12FD0-000

LH FRONT FORK DAMPER ASSY
DAMPER ASSY, FRONT FORK LH

(23) 51140-12FD0-000

TUBE, OUTER GZ125/K2-
.TUBE, OUTER LH

(24) 51167-03B30-000

.BUSH, GUIDE

(25) 51168-38A00-000

SPACER
.SPACER, SEAL

(26) 51153-03B30-000

SEAL OIL FORK
.SEAL, OIL

(27) 51156-03B30-000

.RING, STOPPER

(28) 51173-25D00-000

DUST SEAL
.SEAL, DUST

(29) 51195-25D00-000

OIL LOCK PIECE
.PIECE, OIL LOCK

(30) 51147-06F10-000

.BOLT

(31) 51148-36011-000

.GASKET

(32) 51110-12FD0-000

.TUBE, INNER

(33) 51121-12FA0-000

.BUSH, SLIDE

(34) 51146-12FA0-000

.PIPE, SEAT

(35) 51177-12FA0-000

.SPRING, REBOUND

(36) 51196-12FA0-000

.RING, PISTON

(37) 51171-12FD0-000

SPRING,FR
.SPRING, FRONT

(38) 51192-12FA0-000

.JOINT, SPRING

(39) 51176-25D00-000

SPRING SPACER
.COLLAR, SPRING

(40) 51117-25D00-000

.O RING

(41) 51189-12FA0-000

.BOLT, FORK

	Part number	Description	Qty
# 1	51103-12FA0-000 51103-12FD0-000 5110312FA0000	RH FRONT FORK DAMPER ASSY DAMPER ASSY, FRONT FORK RH	£624,97
# 2	51130-12FA0-000 51130-12FD0-000 5113012FA0000	TUBE INNER .TUBE, OUTER RH	£187,88
# 3	51152-C12-F00J000 51167-03B30-000 51152C12F00J000	.BUSH, GUIDE	£28,27
# 4	51168-12FA0-000 51168-38A00-000 5116812FA0000	SPACER .SPACER, SEAL	£10,74
# 5	51153-C25-D00J000 51153-03B30-000 51153C25D00J000	SEAL OIL FORK .SEAL, OIL	£13,22
# 6	51556-12FA0-000 51156-03B30-000 5155612FA0000	.RING, STOPPER	£8,51
# 7	51173-C25-D00J000 51173-25D00-000 51173C25D00J000	DUST SEAL .SEAL, DUST	£14,06
# 8	51195-C25-D00J000 51195-25D00-000 51195C25D00J000	OIL LOCK PIECE .PIECE, OIL LOCK	£36,62
# 9	51147-C42-AA0J000 51147-06F10-000 51147C42AA0J000	.BOLT	£7,81
# 10	51148-C31-030J000 51148-36011-000 51148C31030J000	.GASKET	£6,11
# 11	51110-12FA0-000 51110-12FD0-000 5111012FA0000	.TUBE, INNER	£216,92
# 12	51121-12FA0-000 5112112FA0000 5112112FA0000	.BUSH, SLIDE	£11,48
# 13	51146-12FA0-000 5114612FA0000 5114612FA0000	.PIPE, SEAT	£35,03
# 14	51177-12FA0-000 5117712FA0000 5117712FA0000	.SPRING, REBOUND	£4,85
# 15	51196-12FA0-000 5119612FA0000 5119612FA0000	.RING, PISTON	£4,91
# 16	51171-12FA0-000 51171-12FD0-000 5117112FA0000	SPRING, FR .SPRING, FRONT	£22,54
# 17	51192-12FA0-000 5119212FA0000 5119212FA0000	.JOINT, SPRING	£2,54
# 18	51176-C25-D00J000 51176-25D00-000 51176C25D00J000	SPRING SPACER .COLLAR, SPRING	£27,34
# 19	51117-C25-D00J000 51117-25D00-000 51117C25D00J000	.O RING	£8,77
# 20	51189-12FA0-000 5118912FA0000 5118912FA0000	.BOLT, FORK	£57,49
# 21	51166-12FA0-000 5116612FA0000 5116612FA0000	.BOLT, RH (8X35)	Not available	£0,00
# 22	51104-12FA0-000 51104-12FD0-000 5110412FA0000	LH FRONT FORK DAMPER ASSY DAMPER ASSY, FRONT FORK LH	£534,35
# 23	51140-12FA0-000 5114012FA0000	TUBE, OUTER GZ125/K2- .TUBE, OUTER LH	Not available	£0,00
# 24	51152-C12-F00J000 51167-03B30-000 51152C12F00J000	.BUSH, GUIDE	£28,27
# 25	51168-12FA0-000 51168-38A00-000 5116812FA0000	SPACER .SPACER, SEAL	£10,74
# 26	51153-C25-D00J000 51153-03B30-000 51153C25D00J000	SEAL OIL FORK .SEAL, OIL	£13,22
# 27	51556-12FA0-000 51156-03B30-000 5155612FA0000	.RING, STOPPER	£8,51
# 28	51173-C25-D00J000 51173-25D00-000 51173C25D00J000	DUST SEAL .SEAL, DUST	£14,06
# 29	51195-C25-D00J000 51195-25D00-000 51195C25D00J000	OIL LOCK PIECE .PIECE, OIL LOCK	£36,62
# 30	51147-C42-AA0J000 51147-06F10-000 51147C42AA0J000	.BOLT	£7,81
# 31	51148-C31-030J000 51148-36011-000 51148C31030J000	.GASKET	£6,11
# 32	51110-12FA0-000 51110-12FD0-000 5111012FA0000	.TUBE, INNER	£216,92
# 33	51121-12FA0-000 5112112FA0000 5112112FA0000	.BUSH, SLIDE	£11,48
# 34	51146-12FA0-000 5114612FA0000 5114612FA0000	.PIPE, SEAT	£35,03
# 35	51177-12FA0-000 5117712FA0000 5117712FA0000	.SPRING, REBOUND	£4,85
# 36	51196-12FA0-000 5119612FA0000 5119612FA0000	.RING, PISTON	£4,91
# 37	51171-12FA0-000 51171-12FD0-000 5117112FA0000	SPRING, FR .SPRING, FRONT	£22,54
# 38	51192-12FA0-000 5119212FA0000 5119212FA0000	.JOINT, SPRING	£2,54
# 39	51176-C25-D00J000 51176-25D00-000 51176C25D00J000	SPRING SPACER .COLLAR, SPRING	£27,34
# 40	51117-C25-D00J000 51117-25D00-000 51117C25D00J000	.O RING	£8,77
# 41	51189-12FA0-000 5118912FA0000 5118912FA0000	.BOLT, FORK	£57,49

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
