SPEEDOMETER (MODEL N P9,MODEL R P31) REFER TO FIG.18B(D-7) FOR MODEL R P9

SPEEDOMETER (MODEL R P9) FOR SUZUKI TS-ER 125 1992

HEADLIGHT REFER TO FIG.20 (D-10) FOR E2

(1) 34120-03D10-000

SPEEDOMETER
SPEEDOMETER (KILO)

(2) 34220-487A0-000

TACHOMETER

(3) 02112-0310A-000

SCREW

(4) 09162-03001-000

REORDER IMS - 01427 617845
LOCK WASHER

(5) 08322-0103B-000

WASHER

(6) 34150-487A0-000

HOOD, METER

(7) 34124-49910-000

KNOB
KNOB, TRIP

(8) 34996-49910-000

SEAL
SEAL, TRIP KNOB

(9) 34111-01A00-000

METER CASE
CASE, METER

(10) 03511-03146-000

.SCREW

(11) 34170-487A0-000

SOCKET, METER

(12) 09471-12082-000

BULB
BULB (12V,3.4W)

(13) 09471-12077-000

BULB 12V1.7W,T10,WB121
BULB (12V,1.7W)

(14) 34950-01A00-000

BRACKET
BRACKET, METER

(15) 34955-28010-000

METER CUSHION
CUSHION

(16) 09160-05048-000

WASHER COVER (5.5X14X1.20)
WASHER

(17) 03111-0412A-000

SCREW

(18) 02112-1612B-000

SCREW

(19) 34162-48780-000

BRACKET, SPEEDOMETER

(20) 09320-09010-000

CUSHION

(21) 09180-06121-000

SPACER
SPACER (6.4X9.2X12)

(22) 09160-06088-000

WASHER
WASHER (6.5X20X1.6)

(23) 09116-06150-000

BOLT
BOLT, METER

(24) 01560-0616A-000

BOLT

(25) 08310-0006A-000

NUT

(26) 34910-13A02-000

SPEEDO CABLE ASSY
CABLE ASSY, SPEEDOMETER

(27) 02112-0516B-000

SCREW

(28) 34938-01A00-000

CLAMP

(29) 02112-0525A-000

SCREW

(30) 08310-0005B-000

NUT

(31) 09407-18402-000

CLAMP
CLAMP, BREATHER TUBE (L:165)

(31) 09407-22404-000

CLAMP
CLAMP, TACHOMETER

(32) 34940-48710-000

CABLE ASSY, TACHOMETER

(33) 58621-38300-000

SUZUKI PART
GUIDE, TACHOMETER CABLE

(33) 34997-48701-000

GUIDE, TACHOMETER CABLE

(34) 02112-7612A-000

SCREW

	Part number	Description	Qty
# 1	34120-03D10-000 3412003D10000 3412003D10000	SPEEDOMETER SPEEDOMETER (KILO)	Not available	£0,00
# 2	34220-487A0-000 34220487A0000 34220487A0000	TACHOMETER	Not available	£0,00
# 3	02112-03103-000 02112-0310A-000 0211203103000	SCREW	£2,84
# 4	08321-21033-000 09162-03001-000 0832121033000	REORDER IMS - 01427 617845 LOCK WASHER	£2,02
# 5	08322-01033-000 08322-0103B-000 0832201033000	WASHER	£3,64
# 6	34150-487A0-000 34150487A0000 34150487A0000	HOOD, METER	Not available	£0,00
# 7	34124-49910-000 3412449910000 3412449910000	KNOB KNOB, TRIP	Not available	£0,00
# 8	34996-49910-000 3499649910000 3499649910000	SEAL SEAL, TRIP KNOB	Not available	£0,00
# 9	34111-01A00-000 3411101A00000 3411101A00000	METER CASE CASE, METER	Not available	£0,00
# 10	36456-45100-000 03511-03146-000 3645645100000	.SCREW	£2,82
# 11	34170-487A0-000 34170487A0000 34170487A0000	SOCKET, METER	Not available	£0,00
# 12	09471-12082-000 0947112082000 0947112082000	BULB BULB (12V, 3.4W)	£7,70
# 13	09471-12077-000 0947112077000 0947112077000	BULB 12V1.7W, T10, WB121 BULB (12V, 1.7W)	£1,74
# 14	34950-01A00-000 3495001A00000 3495001A00000	BRACKET BRACKET, METER	Not available	£0,00
# 15	34955-28010-000 3495528010000 3495528010000	METER CUSHION CUSHION	£6,47
# 16	09160-05036-000 09160-05048-000 0916005036000	WASHER COVER (5.5X14X1.20) WASHER	£2,82
# 17	03112-04123-000 03111-0412A-000 0311204123000	SCREW	£1,39
# 18	02112-16123-000 02112-1612B-000 0211216123000	SCREW	£4,16
# 19	34162-48780-000 3416248780000 3416248780000	BRACKET, SPEEDOMETER	Not available	£0,00
# 20	09320-09010-000 0932009010000 0932009010000	CUSHION	£4,40
# 21	09180-06121-000 0918006121000 0918006121000	SPACER SPACER (6.4X9.2X12)	£2,64
# 22	09160-06088-000 0916006088000 0916006088000	WASHER WASHER (6.5X20X1.6)	£2,12
# 23	09116-06146-000 09116-06150-000 0911606146000	BOLT BOLT, METER	£3,96
# 24	01560-06163-000 01560-0616A-000 0156006163000	BOLT	£2,81
# 25	08310-00063-000 0831000063000	NUT	Not available	£0,00
# 26	34910-13A01-000 34910-13A02-000 3491013A01000	SPEEDO CABLE ASSY CABLE ASSY, SPEEDOMETER	£62,50
# 27	02112-05163-000 02112-0516B-000 0211205163000	SCREW	£2,98
# 28	34938-01A00-000 3493801A00000 3493801A00000	CLAMP	£17,10
# 29	02112-05253-000 02112-0525A-000 0211205253000	SCREW	£2,40
# 30	08310-00053-000 08310-0005B-000 0831000053000	NUT	£2,64
# 31	09407-18403-000 09407-18402-000 0940718403000	CLAMP CLAMP, BREATHER TUBE (L:165)	£1,79
# 31	09407-22404-000 0940722404000 0940722404000	CLAMP CLAMP, TACHOMETER	Not available	£0,00
# 32	34940-48710-000 3494048710000 3494048710000	CABLE ASSY, TACHOMETER	Not available	£0,00
# 33	58621-38300-000 5862138300000 5862138300000	SUZUKI PART GUIDE, TACHOMETER CABLE	£8,44
# 33	34997-48701-000 3499748701000 3499748701000	GUIDE, TACHOMETER CABLE	Not available	£0,00
# 34	02112-76123-000 02112-7612A-000 0211276123000	SCREW	£2,83
