THROTTLE BODY

PUMP ASSY FOR SUZUKI HAYABUSA 1300 2005

AIR FILTER

(1) 15100-24FB0-000

PUMP ASSY, FUEL

(2) 15410-24FB0-000

FILTER FUEL
FILTER ASSY, FUEL

(3) 15420-24FB0-000

STRAINER, FUEL PUMP

(4) 15111-35F00-000

CUSHION, FUEL PUMP

(5) 15112-42F00-000

HOLDER, FUEL PUMP

(6) 15114-35F00-000

BUSH, FUEL PUMP

(7) 15113-35F00-000

O RING

(8) 15115-35F00-000

NUT

(8) 15115-35F00-000

NUT

(9) 15116-35F10-000

SCREW

(9) 15116-35F10-000

SCREW

(9) 15116-35F10-000

SCREW

(9) 15116-35F10-000

SCREW

(10) 34810-24FA0-000

GAUGE ASSY, FUEL LEVEL

(11) 15171-35F00-000

WASHER

(11) 15171-35F00-000

WASHER

(12) 15172-35F00-000

SPRING WASHER

(12) 15172-35F00-000

SPRING WASHER

(13) 15173-35F00-000

NUT

(13) 15173-35F00-000

NUT

(14) 15181-24FB0-000

BRACKET, FUEL GAUGE

(15) 15201-35F00-000

O-RING FUEL PUMP
O RING

(16) 07120-0612B-000

BOLT OIL GALLERY
BOLT

(17) 15810-24FA0-000

HOSE, FUEL

	Part number	Description	Qty
# 1	15100-24FB0-000 1510024FB0000 1510024FB0000	PUMP ASSY, FUEL	£1 014,26
# 2	15410-24FB0-000 1541024FB0000 1541024FB0000	FILTER FUEL FILTER ASSY, FUEL	£520,08
# 3	15420-24FB0-000 1542024FB0000 1542024FB0000	STRAINER, FUEL PUMP	£47,23
# 4	15111-35F00-000 1511135F00000 1511135F00000	CUSHION, FUEL PUMP	£9,94
# 5	15112-42F00-000 1511242F00000 1511242F00000	HOLDER, FUEL PUMP	£30,52
# 6	15114-35F00-000 1511435F00000 1511435F00000	BUSH, FUEL PUMP	£25,13
# 7	15113-35F00-000 1511335F00000 1511335F00000	O RING	£10,01
# 8	15115-35F00-000 1511535F00000 1511535F00000	NUT	£10,75
# 9	15116-35F10-000 1511635F10000 1511635F10000	SCREW	£6,76
# 10	34810-24FA0-000 3481024FA0000 3481024FA0000	GAUGE ASSY, FUEL LEVEL	£217,06
# 11	15171-35F00-000 1517135F00000 1517135F00000	WASHER	£3,89
# 12	15172-35F00-000 1517235F00000 1517235F00000	SPRING WASHER	£3,86
# 13	15173-35F00-000 1517335F00000 1517335F00000	NUT	£3,86
# 14	15181-24FB0-000 1518124FB0000 1518124FB0000	BRACKET, FUEL GAUGE	£62,44
# 15	15201-35F00-000 1520135F00000 1520135F00000	O-RING FUEL PUMP O RING	£11,71
# 16	07120-06123-000 07120-0612B-000 0712006123000	BOLT OIL GALLERY BOLT	£3,60
# 17	15810-24FA0-000 1581024FA0000 1581024FA0000	HOSE, FUEL	£78,42

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the PUMP ASSY of your Suzuki HAYABUSA 1300 of HAYABUSA. Let us know if you have any questions.
