THROTTLE BODY FOR SUZUKI HAYABUSA 1300 2006

PUMP ASSY

Item numbers

THROTTLE BODY ASSY, LH

13401-24FH0-000 1340124FH0000

Not available

THROTTLE BODY ASSY, LH

13401-24FJ0-000 1340124FJ0000

Not available

THROTTLE BODY ASSY, ML

13402-24FH0-000 1340224FH0000

Not available

THROTTLE BODY ASSY, ML

13402-24FJ0-000 1340224FJ0000

Not available

THROTTLE BODY ASSY, MR

13403-24FH0-000 1340324FH0000

Not available

THROTTLE BODY ASSY, MR

13403-24FJ0-000 1340324FJ0000

Not available

THROTTLE BODY ASSY, RH

13404-24FH0-000 1340424FH0000

Not available

THROTTLE BODY ASSY, RH

13404-24FJ0-000 1340424FJ0000

Not available

INJECTOR ASSY

15710-24F00-000 1571024F00000

£340,06

Unit Price Incl. Tax

O RING

15721-24F00-000 1572124F00000

£6,49

Unit Price Incl. Tax

RING, CUSHION

15722-24F00-000 1572224F00000

£20,96

Unit Price Incl. Tax

RING, SEAL

13672-24F00-000 1367224F00000

£25,06

Unit Price Incl. Tax

SCREW

13601-35F00-000 1360135F00000

£11,93

Unit Price Incl. Tax

JOINT LH
JOINT, NO.1

13471-35F00-000 1347135F00000

£46,21

Unit Price Incl. Tax

JOINT ML/MR
JOINT, NO.2, 3

13471-35F10-000 1347135F10000

£50,96

Unit Price Incl. Tax

JOINT RH
JOINT, NO.4

13471-35F20-000 1347135F20000

£46,21

Unit Price Incl. Tax

JOINT

13474-24F00-000 1347424F00000

£46,26

Unit Price Incl. Tax

O RING

15721-24F00-000 1572124F00000

£6,49

Unit Price Incl. Tax

BOLT

13611-24F00-000 1361124F00000

£31,99

Unit Price Incl. Tax

NUT

13607-24F00-000 1360724F00000

£4,31

Unit Price Incl. Tax

SCREW, STOP

13423-35F00-000 1342335F00000

£11,17

Unit Price Incl. Tax

SPRING

13543-24F00-000 1354324F00000

£7,70

Unit Price Incl. Tax

SPRING

13268-03F50-000 1326803F50000

£8,16

Unit Price Incl. Tax

SPRING

13543-24F20-000 1354324F20000

Not available

SCREW, STOP

13602-24F10-000 1360224F10000

Not available

SPRING

13543-24F30-000 1354324F30000

Not available

SCREW
SCREW, STOP

13267-35F00-000 1326735F00000

£40,72

Unit Price Incl. Tax

WASHER

13273-24F00-000 1327324F00000

£4,73

Unit Price Incl. Tax

SPRING

13271-24F00-000 1327124F00000

£7,07

Unit Price Incl. Tax

SENSOR, THROTTLE NO.1

13580-40F20-000

13580-40F21-000

£240,17

Unit Price Incl. Tax

O RING

13575-24F00-000 1357524F00000

£7,70

Unit Price Incl. Tax

SCREW

13605-40F00-000 1360540F00000

Not available

CLAMP

13432-24F10-000 1343224F10000

£15,49

Unit Price Incl. Tax

CLAMP

13619-24F10-000 1361924F10000

Not available

HOSE RUBBER (L 35)

13697-24F00-000

13697-24F01-000

£3,32

Unit Price Incl. Tax

HOSE RUBBER (L 100)

13697-24F20-000

13697-24F21-000

£4,90

Unit Price Incl. Tax

HOSE RUBBER (L 200)

13697-24F30-000

13697-24F31-000

£10,64

Unit Price Incl. Tax

HOSE RUBBER (L 230+20)

13697-24FA0-000

13697-24FA1-000

£20,64

Unit Price Incl. Tax

JOINT

13471-24F30-000 1347124F30000

£21,54

Unit Price Incl. Tax

BAND
CLAMP

13432-24FA0-000 1343224FA0000

Not available

PLATE, STAY

13565-24F00-000 1356524F00000

Not available

SCREW

13601-24F00-000 1360124F00000

Not available

JOINT

13473-35F01-000 1347335F01000

£139,99

Unit Price Incl. Tax

HOSE GSX1300R
HOSE, RUBBER (L:80+25)

13698-24F00-000 1369824F00000

Not available

HOSE, RUBBER (L:35)

13698-24F10-000 1369824F10000

Not available

HOSE GSX1300R
HOSE, RUBBER (L:30+30)

13698-24F20-000 1369824F20000

Not available

HOSE GSX1300R
HOSE, RUBBER (L:440+30)

13698-24F30-000 1369824F30000

£37,09

Unit Price Incl. Tax

CLIP

13693-24F00-000 1369324F00000

£4,40

Unit Price Incl. Tax

JOINT

13685-36E50-000 1368536E50000

Not available

CLIP

09401-09403-000 0940109403000

£2,69

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the THROTTLE BODY of your Suzuki HAYABUSA 1300 of HAYABUSA. Let us know if you have any questions.
