TAIL LIGHT (E2, E26) REFER TO FIG.23A(E-7) FOR MODEL N/P/R E24

TAIL LIGHT (MODEL N / P / R E24) FOR SUZUKI TS-ER 185 1982

ELECTRICAL (MODEL Z / K,MODEL P E6,P9) REFER TO FIG 25A(E-10) FOR MODEL N,MODEL P/R E24

(1) 35720-48560-999

REAR LAMP ASSY
LAMP UNIT, TAIL

(2) 35712-02460-000

LENS

(3) 35713-48510-000

REORDER ROBINSONS
GASKET

(4) 03211-04306-000

SCREW

(5) 35627-43010-000

GASKET

(6) 08322-0105B-000

WASHER
.WASHER, UPPER

(7) 08321-0105A-000

LOCK WASHER
.LOCK WASHER, HOLDER

(8) 02112-0512A-000

SCREW
.SCREW, CAP

(9) 09471-06034-000

BULB (6V, 21/5W)

(10) 35730-30910-000

BRACKET UNIT,TAIL LAMP
BRACKET ASSY

(11) 35716-30950-000

REORDER BRAN BARDSLEY
PLATE

(12) 35765-30950-000

CUSHION

(13) 35766-30950-000

SPACER

(14) 01570-0630A-000

BOLT

(14) 01550-06307-000

BOLT (1)
BOLT

(15) 09160-06077-000

WASHER
WASHER (6.5X20X1.2) REFER TO FIG.8A (C-6) FOR MODE REFER TO FIG.8B (C-7) FOR MODE

(16) 08321-01067-000

LOCK WASHER

(17) 09180-06271-000

SPACER
SPACER (6.4X9X18)

(18) 09320-09003-000

CUSHION

(19) 01500-0640B-000

BOLT
BOLT (6X40)

(19) 01570-06403-000

BOLT

(20) 08321-01067-000

LOCK WASHER

(21) 09180-06289-000

SPACER
SPACER (6.8X10X11.5)

(21) 09180-07019-000

SPACER(7.2X10X11.5)
SPACER (6.8X10X11.5)

(22) 09320-09010-000

CUSHION

(23) 09308-07004-000

GROMMET

	Part number	Description	Qty
# 1	35720-48560-999 3572048560999 3572048560999	REAR LAMP ASSY LAMP UNIT, TAIL	Not available	£0,00
# 2	35712-02460-000 3571202460000 3571202460000	LENS	Not available	£0,00
# 3	35713-48510-000 3571348510000 3571348510000	REORDER ROBINSONS GASKET	£17,44
# 4	03211-04306-000 0321104306000 0321104306000	SCREW	£2,82
# 5	35627-43010-000 3562743010000 3562743010000	GASKET	£3,40
# 6	08322-21055-000 08322-0105B-000 0832221055000	WASHER .WASHER, UPPER	£3,00
# 7	08321-21055-000 08321-0105A-000 0832121055000	LOCK WASHER .LOCK WASHER, HOLDER	£2,44
# 8	02112-05125-000 0211205125000	SCREW .SCREW, CAP	Not available	£0,00
# 9	09471-06034-000 0947106034000 0947106034000	BULB (6V, 21/5W)	Not available	£0,00
# 10	35730-30910-000 3573030910000 3573030910000	BRACKET UNIT, TAIL LAMP BRACKET ASSY	£114,66
# 11	35716-30950-000 3571630950000 3571630950000	REORDER BRAN BARDSLEY PLATE	£57,25
# 12	35765-30950-000 3576530950000 3576530950000	CUSHION	£38,32
# 13	35766-30950-000 3576630950000 3576630950000	SPACER	£3,47
# 14	01550-06307-000 0155006307000 0155006307000	BOLT (1) BOLT	£3,89
# 14	01570-06303-000 01570-0630A-000 0157006303000	BOLT	£7,24
# 15	09160-06027-000 09160-06077-000 0916006027000	WASHER WASHER (6.5X20X1.2) REFER TO FIG.8A (C-6) FOR MODE REFER TO FIG.8B (C-7) FOR MODE	£2,59
# 16	08321-01067-000 0832101067000 0832101067000	LOCK WASHER	£2,44
# 17	09180-06072-000 09180-06271-000 0918006072000	SPACER SPACER (6.4X9X18)	£3,40
# 18	09320-09003-000 0932009003000 0932009003000	CUSHION	£3,90
# 19	01107-06408-000 01500-0640B-000 0110706408000	BOLT BOLT (6X40)	£4,16
# 19	01570-06403-000 0157006403000 0157006403000	BOLT	Not available	£0,00
# 20	08321-01067-000 0832101067000 0832101067000	LOCK WASHER	£2,44
# 21	09180-06006-000 09180-07019-000 0918006006000	SPACER(7.2X10X11.5) SPACER (6.8X10X11.5)	£2,63
# 21	09180-06112-000 09180-06289-000 0918006112000	SPACER SPACER (6.8X10X11.5)	£3,42
# 22	09320-09010-000 0932009010000 0932009010000	CUSHION	£4,40
# 23	09308-07004-000 0930807004000 0930807004000	GROMMET	£3,29

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
