CARBURETOR FOR SUZUKI DR 200 2002

AIR FILTER

Item numbers

CARBURETOR ASSY

13200-42AC0-000 1320042AC0000

Not available

CARBURETOR ASSY

13200-42AE0-000 1320042AE0000

Not available

COVER

13502-42A00-000 1350242A00000

£51,83

Unit Price Incl. Tax

PLUNGER SPRING
SPRING

13417-42A00-000 1341742A00000

£11,18

Unit Price Incl. Tax

WASHER
RING

13382-42A00-000 1338242A00000

£7,37

Unit Price Incl. Tax

NEEDLE CLIP
CLIP, NEEDLE

13394-10010-000 1339410010000

£6,91

Unit Price Incl. Tax

RING NEEDLE JET
RING

13387-47010-000 1338747010000

£11,96

Unit Price Incl. Tax

JET, NEEDLE (P-5M)

09494-00881-000 0949400881000

Not available

DIAPHRAGM ASSY

13500-42A00-000

13500-42A01-000

£135,10

Unit Price Incl. Tax

SCREW

13602-43410-000 1360243410000

£4,66

Unit Price Incl. Tax

PLUNGER ASSY

13411-42A20-000 1341142A20000

£55,21

Unit Price Incl. Tax

O RING, PILOT AIR SCREW

13295-29900-000

13295-29901-000

£4,48

Unit Price Incl. Tax

WASHER

13291-29900-000 1329129900000

£2,84

Unit Price Incl. Tax

SPRING

13268-47070-000 1326847070000

£7,39

Unit Price Incl. Tax

PILOT SCREW
SCREW, PILOT (1 1/2)

13279-47070-000 1327947070000

£10,06

Unit Price Incl. Tax

PILOT JET 35
JET, PILOT (35)

09492-35008-000 0949235008000

£15,64

Unit Price Incl. Tax

WASHER

13382-03110-000 1338203110000

£4,66

Unit Price Incl. Tax

MAIN JET
JET, MAIN (125)

09491-25010-000 0949125010000

£12,32

Unit Price Incl. Tax

NEEDLE, JET (5D77-1)

13383-42AC0-000 1338342AC0000

Not available

FLOAT

13250-42A00-000 1325042A00000

£57,26

Unit Price Incl. Tax

FLOAT PIN
PIN, FLOAT

13254-92311-000 1325492311000

£2,59

Unit Price Incl. Tax

NEEDLE VALVE ASSY
VALVE ASSY, NEEDLE

13370-44500-000 1337044500000

£28,46

Unit Price Incl. Tax

FLOAT CHAMBER GASKET
O RING, FLOAT CHAMBER

13251-42A00-000 1325142A00000

£10,36

Unit Price Incl. Tax

O RING

13374-35C00-000 1337435C00000

£4,93

Unit Price Incl. Tax

FILTER

13376-19F00-000 1337619F00000

£17,10

Unit Price Incl. Tax

JET, AIR (135)

09493-27001-000 0949327001000

£22,69

Unit Price Incl. Tax

SCREW

02112-04123-000

02112-0412A-000

£1,74

Unit Price Incl. Tax

SPRING

13268-37420-000 1326837420000

£7,39

Unit Price Incl. Tax

ADJUSTER

13267-25D00-000 1326725D00000

£18,56

Unit Price Incl. Tax

HOSE(5X8.2X600)

09352-50823-600

09352-50005-600

£6,34

Unit Price Incl. Tax

HOSE

09355-45855-600

09355-45001-600

£9,54

Unit Price Incl. Tax

SCREW
SCREW, DRAIN

13247-13A00-000 1324713A00000

£11,96

Unit Price Incl. Tax

PLUG

13281-05A00-000 1328105A00000

£7,69

Unit Price Incl. Tax

SCREW

02112-04083-000

02112-0408A-000

£1,99

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the CARBURETOR of your Suzuki of DR. Let us know if you have any questions.
