WATER PUMP

RADIATOR FOR SUZUKI TS-R 200 1992

CLUTCH

Item numbers

RADIATOR ASSY
RADIATOR, WATER RH

17710-03D12-000 1771003D12000

Not available

RADIATOR COMP, WATER, L
RADIATOR, WATER LH

17720-08D00-000 1772008D00000

Not available

RADIATOR CAP

17730-03D00-000

Not available

SCREW RADIATOR CAP

17733-03D00-000

17733-03D10-000

£3,73

Unit Price Incl. Tax

CUSHION
CUSHION, RADIATOR

17787-19A00-000 1778719A00000

£2,95

Unit Price Incl. Tax

SPACER

09180-07004-000 0918007004000

£3,86

Unit Price Incl. Tax

WASHER

09160-06113-000

09160-06114-000

£3,40

Unit Price Incl. Tax

BOLT OIL STRAINER

01517-06254-000

01550-0625B-000

£3,84

Unit Price Incl. Tax

REORDER ROBINSONS
BOLT (6X20)

09116-06149-000 0911606149000

£5,51

Unit Price Incl. Tax

HOSE, RADIATOR JOINT NO.2

17851-08D00-000

Not available

HOSE, RDTR OUTLET, NO.1
HOSE, RADIATOR, OUTLET

17852-08D00-000 1785208D00000

Not available

HOSE, RDTR INLET, NO.2
HOSE, RADIATOR, INLET

17853-08D00-000 1785308D00000

Not available

HOSE, RDTR OUTLET, NO.2
HOSE, RADIATOR, OUTLET

17854-08D00-000 1785408D00000

Not available

CLAMP

09402-25502-000

09402-28511-000

£7,85

Unit Price Incl. Tax

RADIATOR COVER
COVER, RADIATOR, RH (BLUE)

17761-03D00-0NF 1776103D000NF

Not available

RADIATOR COVER
COVER, RADIATOR, RH (YELLOW)

17761-03D00-25Y 1776103D0025Y

Not available

EMBLEM, RADIATOR COVER, RH

68661-08D10-3MB 6866108D103MB

Not available

EMBLEM, RADIATOR COVER, R
EMBLEM, RADIATOR COVER, RH

68661-08D10-B13 6866108D10B13

Not available

REORDER ROBINSONS
TAPE, RADIATOR COVER, RH

68665-03D10-N52 6866503D10N52

Not available

TAPE, RADIATOR COVER, RH

68665-03D10-N53 6866503D10N53

Not available

TAPE, RADIATOR COVER, R
TAPE, RADIATOR COVER, RH

68665-03D20-A4H 6866503D20A4H

Not available

TAPE, RADIATOR COVER, R
TAPE, RADIATOR COVER, RH

68665-03D20-A6L 6866503D20A6L

Not available

RADIATOR COVER
COVER, RADIATOR, LH (YELLOW)

17762-03D00-25Y 1776203D0025Y

£78,97

Unit Price Incl. Tax

RADIATOR COVER
COVER, RADIATOR, LH (BLUE)

17762-03D00-0NF 1776203D000NF

Not available

EMBLEM, RADIATOR, LH

68671-08D10-3MB 6867108D103MB

Not available

EMBLEM, RADIATOR COVER, L
EMBLEM, RADIATOR, LH

68671-08D10-B13 6867108D10B13

Not available

REORDER ROBINSONS
TAPE, RADIATOR COVER, LH

68675-03D10-N52 6867503D10N52

Not available

TAPE, RADIATOR COVER, LH

68675-03D10-N53 6867503D10N53

Not available

TAPE, RADIATOR COVER, LH

68675-03D20-A4H 6867503D20A4H

Not available

TAPE, RADIATOR COVER, L
TAPE, RADIATOR COVER, LH

68675-03D20-A6L 6867503D20A6L

Not available

SCREW

02142-06108-000

02142-06107-000

£3,49

Unit Price Incl. Tax

RADIATOR LOUVER
LOUVER, RADIATOR

17821-03D00-000 1782103D00000

Not available

SPRING

09446-11002-000

09446-11002-XC0

£3,49

Unit Price Incl. Tax

RADIATOR LOUVER GUARD
GUARD, RADIATOR LOUVER, RH

17822-03D00-000 1782203D00000

Not available

RADIATOR LOUVER GUARD
GUARD, RADIATOR LOUVER, LH

17823-03D00-000 1782303D00000

Not available

RESERVE TANK ASSY

17910-03D00-000

17910-03D01-000

£51,56

Unit Price Incl. Tax

TANK CAP
CAP

17845-13700-000 1784513700000

Not available

GASKET ASB
GASKET

17844-13700-000 1784413700000

Not available

HOSE 5X9X600

09352-50901-300

09352-50901-600

£8,99

Unit Price Incl. Tax

CLIP GSX-R600/K6-

09401-08407-000

09401-08411-000

£2,28

Unit Price Incl. Tax

HOSE 5X9X2000

09352-50901-00A

09352-50901-00B

£28,64

Unit Price Incl. Tax

HOLDER, RESERVE TANK

17920-03D00-000 1792003D00000

Not available

BOLT

01517-06164-000

01550-06163-000

£3,22

Unit Price Incl. Tax

PLATE
PLATE, RESERVE TANK CAP

17934-03D00-000 1793403D00000

Not available

SCREW CENTER SHAFT

02112-06104-000

Not available

SCREW
SCREW (6X6)

09136-06061-000 0913606061000

£3,02

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the RADIATOR of your Suzuki of TS-R. Let us know if you have any questions.
