FUEL TANK (MODEL M E21) FOR SUZUKI DR 250 1993

FUEL TANK (MODEL N / P / R E24) REFER TO FIG.30C(E-11) FOR MODEL N/P/R E21

(1) 49100-15D10-28X

TANK ASSY, FUEL (WHITE)

(1) 49100-15D10-30H

TANK ASSY, FUEL (WHITE)

(2) 68110-15D30-0WE

TAPE, FUEL TANK

(2) 68110-15D30-0WG

TAPE, FUEL TANK

(3) 44200-03811-000

CAP SET
CAP SET, FUEL TANK

(4) 44171-15D00-30H

FUEL TANK COVER RH
COVER, FUEL TANK RH (WHITE)

(5) 44181-15D00-30H

FUEL TANK COVER LH
COVER, FUEL TANK LH (WHITE)

(6) 02142-06107-000

SCREW
SCREW, FRONT

(7) 09136-06002-000

SCREW
SCREW, REAR

(8) 44541-15D01-000

CUSHION
HEAT SHIELD, FUEL TANK

(9) 02142-05087-000

SCREW

(10) 09404-06039-000

CLAMP L:65
CLAMP, THROTTLE CABLE

(11) 09329-10016-000

CUSHION
CUSHION, FRONT

(12) 09116-06172-000

BOLT (6X30)
BOLT, REAR

(13) 09320-14013-000

CUSHION
CUSHION, UPPER

(14) 09180-06271-000

SPACER
SPACER (6.4X9X18)

(15) 09320-10071-000

CUSHION(9X24X18)
CUSHION, LOWER

	Part number	Description	Qty
# 1	49100-15D10-28X 4910015D1028X 4910015D1028X	TANK ASSY, FUEL (WHITE)	Not available	£0,00
# 1	49100-15D10-30H 4910015D1030H 4910015D1030H	TANK ASSY, FUEL (WHITE)	Not available	£0,00
# 2	68110-15D30-0WE 6811015D300WE 6811015D300WE	TAPE, FUEL TANK	Not available	£0,00
# 2	68110-15D30-0WG 6811015D300WG 6811015D300WG	TAPE, FUEL TANK	Not available	£0,00
# 3	44200-03811-000 4420003811000 4420003811000	CAP SET CAP SET, FUEL TANK	Not available	£0,00
# 4	44171-15D00-30H 4417115D0030H 4417115D0030H	FUEL TANK COVER RH COVER, FUEL TANK RH (WHITE)	Not available	£0,00
# 5	44181-15D00-30H 4418115D0030H 4418115D0030H	FUEL TANK COVER LH COVER, FUEL TANK LH (WHITE)	Not available	£0,00
# 6	02142-06108-000 02142-06107-000 0214206108000	SCREW SCREW, FRONT	£3,49
# 7	09136-06002-000 0913606002000 0913606002000	SCREW SCREW, REAR	£3,20
# 8	49131-14D10-000 4913114D10000	CUSHION HEAT SHIELD, FUEL TANK	Not available	£0,00
# 9	02142-05087-000 0214205087000 0214205087000	SCREW	£1,92
# 10	09404-05404-000 09404-06039-000 0940405404000	CLAMP L:65 CLAMP, THROTTLE CABLE	£1,94
# 11	09329-10016-000 0932910016000 0932910016000	CUSHION CUSHION, FRONT	£4,99
# 12	09116-06153-000 09116-06172-000 0911606153000	BOLT (6X30) BOLT, REAR	£3,34
# 13	09320-14013-000 0932014013000 0932014013000	CUSHION CUSHION, UPPER	£3,40
# 14	09180-06072-000 09180-06271-000 0918006072000	SPACER SPACER (6.4X9X18)	£3,40
# 15	09320-10020-000 09320-10071-000 0932010020000	CUSHION(9X24X18) CUSHION, LOWER	£2,56

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the FUEL TANK (MODEL M E21) of your Suzuki of DR. Let us know if you have any questions.
