TAIL LIGHT (E25,E39) FOR SUZUKI GN 250 1989

WIRING HARNESS

(1) 35720-38361-000

LAMP UNIT,REAR C
LAMP UNIT, TAIL

(2) 35712-38361-000

LENS

(3) 35713-30510-000

GASKET, LAMP LENS
GASKET

(4) 09471-12083-000

BULB (12V,21/5W)

(5) 02112-04558-000

SCREW 4X55
SCREW

(6) 35627-43010-000

GASKET

(7) 02112-06167-000

SCREW

(8) 08321-01067-000

LOCK WASHER

(9) 08310-00067-000

NUT

(10) 35730-38380-000

BRACKET UNIT,TAIL LAMP GN125
BRACKET UNIT

(11) 35766-26470-000

SPACER

(12) 35765-26470-000

CUSHION

(13) 35764-26470-000

CUSHION

(14) 01500-06207-000

BOLT

(15) 09160-06077-000

WASHER
WASHER (6.5X20X1.2) REFER TO FIG.8A (C-6) FOR MODE REFER TO FIG.8B (C-7) FOR MODE

(16) 08322-0106A-000

WASHER

(17) 08310-00067-000

.NUT

(18) 09308-09004-000

REORD BARDSLEY
GROMMET

	Part number	Description	Qty
# 1	35720-38361-000 3572038361000 3572038361000	LAMP UNIT, REAR C LAMP UNIT, TAIL	Not available	£0,00
# 2	35712-38361-000 3571238361000 3571238361000	LENS	Not available	£0,00
# 3	35713-30510-000 3571330510000 3571330510000	GASKET, LAMP LENS GASKET	Not available	£0,00
# 4	09471-12057-000 09471-12083-000 0947112057000	BULB (12V, 21/5W)	£8,78
# 5	09125-04002-000 02112-04558-000 0912504002000	SCREW 4X55 SCREW	£2,72
# 6	35627-43010-000 3562743010000 3562743010000	GASKET	£3,40
# 7	02112-06167-000 0211206167000 0211206167000	SCREW	£2,58
# 8	08321-01067-000 0832101067000 0832101067000	LOCK WASHER	£2,44
# 9	08310-00067-000 0831000067000 0831000067000	NUT	£2,44
# 10	35730-38380-000 3573038380000 3573038380000	BRACKET UNIT, TAIL LAMP GN125 BRACKET UNIT	Not available	£0,00
# 11	35766-26470-000 3576626470000 3576626470000	SPACER	£4,14
# 12	35765-26470-000 3576526470000 3576526470000	CUSHION	£20,93
# 13	35764-26470-000 3576426470000 3576426470000	CUSHION	£5,09
# 14	01500-06207-000 0150006207000 0150006207000	BOLT	£3,24
# 15	09160-06027-000 09160-06077-000 0916006027000	WASHER WASHER (6.5X20X1.2) REFER TO FIG.8A (C-6) FOR MODE REFER TO FIG.8B (C-7) FOR MODE	£2,59
# 16	08322-01067-000 08322-0106A-000 0832201067000	WASHER	£3,16
# 17	08310-11067-000 08310-00067-000 0831011067000	.NUT	£2,44
# 18	09308-09004-000 0930809004000 0930809004000	REORD BARDSLEY GROMMET	£3,71

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
