RADIATOR

SWINGARM FOR SUZUKI RM-Z 250 2004

SUSPENSION

Item numbers

132

BOLT, FLANGED, SMALL

KK132-V0650-000

K132B-A0650-000

£3,78

Unit Price Incl. Tax

12053A

GUIDE-CHAIN

K1205-31468-000 K120531468000

£78,42

Unit Price Incl. Tax

12053

GUIDE-CHAIN, DRIVE, FR

K1205-30019-000 K120530019000

Not available

13271

PLATE, AXLE

K1327-11833-000 K132711833000

Not available

13271A

PLATE, CHAIN GUIDE

K1327-11834-000 K132711834000

Not available

33001

ARM-COMP-SWING
ARM-COMP-SWING, SILVER

KK330-01000-2CE KK330010002CE

Not available

33032

SHAFT-SWING ARM

K3303-21189-000 K330321189000

Not available

33040

ADJUSTER-CHAIN RH

K3304-00013-000

K3304-00020-000

£24,61

Unit Price Incl. Tax

33040A

ADJUSTER-CHAIN LH

K3304-01189-000

K3304-00075-000

£17,09

Unit Price Incl. Tax

42036

SLEEVE, SWING ARM, L=46

K4203-60003-000 K420360003000

Not available

92009

SCREW, 5X10

K9200-91828-000 K920091828000

Not available

92015

NUT, FLANGED, 8MM

K9201-51014-000 K920151014000

£6,76

Unit Price Incl. Tax

92015A

NUT FLANGED 6MM

K9201-51078-000

K9221-00630-000

£2,14

Unit Price Incl. Tax

92015B

NUT, FLANGED, 16MM

K9201-51316-000 K920151316000

Not available

92046

BEARING-NEEDLE, TA2230Z

K9204-61174-000 K920461174000

£84,25

Unit Price Incl. Tax

92046A

BEARING-NEEDLE, NTBR22356E01

K9204-61240-000 K920461240000

£41,08

Unit Price Incl. Tax

92093

SEAL, SDO29X35X4.5

K9209-31434-000 K920931434000

£15,02

Unit Price Incl. Tax

92093A

SEAL, SDO22X29X5

K9209-31435-000 K920931435000

£14,95

Unit Price Incl. Tax

92143

COLLAR

K9214-31676-000 K921431676000

£10,26

Unit Price Incl. Tax

92143A

COLLAR, 6.5X14X24

K9214-31867-000 K921431867000

£10,26

Unit Price Incl. Tax

92150

BOLT, 6X12

K9215-01599-000 K921501599000

£4,33

Unit Price Incl. Tax

92152

COLLAR, 17.1X29X7.5

K9215-21137-000 K921521137000

£11,36

Unit Price Incl. Tax

92153

BOLT, 8X56

K9215-30620-000 K921530620000

£5,51

Unit Price Incl. Tax

92172

SCREW, 5X8

K9217-20119-000 K921720119000

£2,95

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the SWINGARM of your Suzuki of RM-Z. Let us know if you have any questions.
