TAIL LIGHT (E17)

WIRING HARNESS (MODEL X / Y) FOR SUZUKI OZARK 250 2000

WIRING HARNESS (MODEL K1 / K2)

(1) 36610-39DH0-000

WIRING HARNESS

(1) 36610-39DL0-000

WIRING HARNESS

(1) 36610-39DM0-000

DISCONTINUED
WIRING HARNESS

(2) 36611-38A10-000

DIODE

(3) 36634-93910-000

REORDER ROBINSONS
CAP

(4) 09403-16307-000

CLAMP

(5) 09404-06039-000

CLAMP (L:65)

(6) 09407-12402-000

CLAMP
CLAMP (L:120)

(6) 09407-14403-000

CLAMP
CLAMP (L:125)

(6) 09407-18402-000

CLAMP
CLAMP (L:185)

(7) 38852-19B10-000

LABEL
LABEL, CAUTION MAX AMP

(8) 36851-39D00-000

CABLE
LEAD WIRE, EMAGENCY SWITCH

(9) 38730-19B00-000

RELAY
RELAY, NEUTRAL START

(10) 36740-24B01-000

FUSE CASE ASSY
BOX ASSY, MAIN FUSE

(11) 09481-20101-000

FUSE
FUSE (20A)

(12) 36740-04701-000

FUSE CASE ASSY
BOX ASSY, POWER SOURCE FUSE

(13) 09481-15101-000

FUSE (15A)

(14) 47410-19B00-000

REORDER ROBINSONS
HOLDER, ELECTRIC PARTS FRONT

(15) 09118-06103-000

BOLT (6X12)

(16) 37110-19B03-000

IGNITION SWITCH ASSY
SWITCH ASSY, IGNITION

(17) 37142-19B01-000

MASCOT, KEY

(18) 38500-09F01-000

HORN ASSY

(18) 38500-39D00-000

HORN ASSY

(19) 37830-27H00-000

SWITCH, HORN LT-A400F/L4
SWITCH ASSY, HORN

(20) 39602-18A00-000

PLUG ASSY
PLUG ASSY, POWER SOURCE

(21) 37146-19B00-000

KEY BLANK C -TYPE (A68)
KEY, BLANK TYPE C

(21) 37146-19B10-000

BLANK KEY TYPE D
KEY, BLANK TYPE D

(22) 36856-35B01-000

WIRE, FRONT BRAKE SW LEAD

(23) 37820-19B00-000

SWITCH ASSY, EMERGENCY

(24) 37825-24500-000

WIRE, EMERGENCY SWITCH

(25) 37740-25C01-000

SWITCH ASSY, STOP LAMP

(26) 09443-06023-000

SPRING

(27) 38740-26E01-000

RELAY TL1000R GSF600/S-X
RELAY ASSY, BACK UP LAMP

(2A) 32800-16A00-000

RECTIFIER ASSY
DIODE

	Part number	Description	Qty
# 1	36610-39DH0-000 3661039DH0000 3661039DH0000	WIRING HARNESS	Not available	£0,00
# 1	36610-39DL0-000 3661039DL0000 3661039DL0000	WIRING HARNESS	Not available	£0,00
# 1	36610-39DM0-000 3661039DM0000 3661039DM0000	DISCONTINUED WIRING HARNESS	Not available	£0,00
# 2	36611-38A00-000 36611-38A10-000 3661138A00000	DIODE	£26,92
# 2A	32800-16A00-000 3280016A00000 3280016A00000	RECTIFIER ASSY DIODE	£37,73
# 3	36634-93910-000 3663493910000 3663493910000	REORDER ROBINSONS CAP	£5,22
# 4	09403-16307-000 0940316307000 0940316307000	CLAMP	£2,69
# 5	09404-06432-000 09404-06039-000 0940406432000	CLAMP (L:65)	£1,94
# 6	09407-12402-000 0940712402000 0940712402000	CLAMP CLAMP (L:120)	£4,03
# 6	09407-14403-000 0940714403000 0940714403000	CLAMP CLAMP (L:125)	£2,84
# 6	09407-18402-000 0940718402000 0940718402000	CLAMP CLAMP (L:185)	£1,79
# 7	38852-19B10-000 3885219B10000 3885219B10000	LABEL LABEL, CAUTION MAX AMP	Not available	£0,00
# 8	36851-39D00-000 3685139D00000 3685139D00000	CABLE LEAD WIRE, EMAGENCY SWITCH	Not available	£0,00
# 9	38730-19B00-000 3873019B00000 3873019B00000	RELAY RELAY, NEUTRAL START	£50,30
# 10	36740-24B01-000 3674024B01000 3674024B01000	FUSE CASE ASSY BOX ASSY, MAIN FUSE	£38,03
# 11	09481-20101-000 0948120101000 0948120101000	FUSE FUSE (20A)	£2,69
# 12	36740-04701-000 3674004701000 3674004701000	FUSE CASE ASSY BOX ASSY, POWER SOURCE FUSE	£33,02
# 13	09481-15101-000 0948115101000 0948115101000	FUSE (15A)	£2,69
# 14	47410-19B00-000 4741019B00000 4741019B00000	REORDER ROBINSONS HOLDER, ELECTRIC PARTS FRONT	£13,66
# 15	09118-06103-000 0911806103000 0911806103000	BOLT (6X12)	£3,64
# 16	37110-19B02-000 37110-19B03-000 3711019B02000	IGNITION SWITCH ASSY SWITCH ASSY, IGNITION	£90,59
# 17	37142-19B00-000 37142-19B01-000 3714219B00000	MASCOT, KEY	£5,74
# 18	38500-09F01-000 3850009F01000 3850009F01000	HORN ASSY	Not available	£0,00
# 18	38500-39D00-000 3850039D00000 3850039D00000	HORN ASSY	Not available	£0,00
# 19	37830-18A00-000 37830-27H00-000 3783018A00000	SWITCH, HORN LT-A400F/L4 SWITCH ASSY, HORN	£26,06
# 20	39602-18A00-000 3960218A00000 3960218A00000	PLUG ASSY PLUG ASSY, POWER SOURCE	£76,61
# 21	37146-19B00-000 3714619B00000 3714619B00000	KEY BLANK C -TYPE (A68) KEY, BLANK TYPE C	£9,52
# 21	37146-19B10-000 3714619B10000 3714619B10000	BLANK KEY TYPE D KEY, BLANK TYPE D	£9,52
# 22	36856-35B00-000 36856-35B01-000 3685635B00000	WIRE, FRONT BRAKE SW LEAD	£11,40
# 23	37820-19B00-000 3782019B00000 3782019B00000	SWITCH ASSY, EMERGENCY	£41,46
# 24	37825-24500-000 3782524500000 3782524500000	WIRE, EMERGENCY SWITCH	£28,09
# 25	37740-25C00-000 37740-25C01-000 3774025C00000	SWITCH ASSY, STOP LAMP	£97,02
# 26	09443-06023-000 0944306023000 0944306023000	SPRING	£5,17
# 27	38740-26E00-000 38740-26E01-000 3874026E00000	RELAY TL1000R GSF600/S-X RELAY ASSY, BACK UP LAMP	£28,16

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
