SPEEDOMETER FOR SUZUKI BANDIT 400 1991

HEADLIGHT (MODEL M / N) REFER TO FIG.27 (E-7) FOR MODEL M/N E4,E16,E21,E22,E25,E34,E53

(1) 34110-10D40-000

SPEEDOMETER
SPEEDOMETER (MILE/KILO)

(1) 34110-10D90-000

SPEEDOMETER
SPEEDOMETER (KILO)

(2) 34111-10D00-000

SPEEDO CASE
CASE, SPEEDOMETER

(3) 34210-10D01-000

TACHOMETER

(4) 34211-10D01-000

TACHO CASE
CASE, TACHOMETER

(5) 34183-10D10-000

SCREW
SCREW, METER

(6) 36380-10D00-000

BOX, PILOT

(6) 36380-10D90-000

P BOX
BOX, PILOT

(7) 36393-10D00-000

UPPER CASE
CASE, UPPER

(8) 36381-10D00-000

INNER CASE
CASE, INNER

(9) 36300-10840-000

LENS SET
LENS SET, PILOT

(10) 03111-0412A-000

.SCREW

(11) 34170-10D00-000

REORDER ROBINSONS
SOCKET

(12) 36383-10D00-000

REORDER ROBINSONS
CASE, LOWER

(13) 03111-14163-000

SCREW

(14) 07130-0520B-000

BOLT

(15) 34118-10D00-000

PLATE

(16) 09471-12082-000

BULB
BULB (12V,3.4W)

(17) 09471-12085-000

BULB (12V3W,WB371,T7)
BULB (12V,3W)

(18) 09471-12100-000

BULB
BULB (12V,1.7W)

(19) 34950-11D00-000

REORDER ROBINSONS
BRACKET, METER

(19) 34950-33D90-000

BRACKET, METER

(20) 01500-0630A-000

BOLT

(20) 01500-06307-000

REORDER ROBINSONS
BOLT, RH

(21) 09160-06066-000

WASHER
.WASHER (6.5*20*1.6)

(21) 09160-06088-000

WASHER
WASHER (6.5X20X1.6)

(22) 09180-06251-000

SPACER
SPACER (6.1X9X15.5)

(23) 09320-09040-000

CUSHION

(24) 08319-3105A-000

NUT

(25) 34161-10D02-000

REORDER ROBINSONS
CUSHION, PILOT LAMP

(26) 34910-11D02-000

SPEEDO CABLE ASSY
CABLE ASSY, SPEEDOMETER

(27) 34910-33D02-000

CABLE ASSY, SPEEDOMETER

(28) 34910-33D02-000

CABLE ASSY, SPEEDOMETER

(29) 02112-0516B-000

SCREW

(30) 34938-10D0V-000

CLAMP, SPEEDOMETER CABLE

(31) 34938-10D1V-000

GUIDE
CLAMP, SPEEDOMETER CABLE

(32) 01550-0612B-000

SCREW AIR CLEANER
BOLT

(32) 01550-06207-000

BOLT
DISCONTINUED

(33) 34938-11D00-000

REORDER ROBINSONS
CLAMP, SPEEDOMETER CABLE

(34) 09103-10195-000

BOLT
BOLT (10X12)

	Part number	Description	Qty
# 1	34110-10D40-000 3411010D40000 3411010D40000	SPEEDOMETER SPEEDOMETER (MILE/KILO)	Not available	£0,00
# 1	34110-10D90-000 3411010D90000 3411010D90000	SPEEDOMETER SPEEDOMETER (KILO)	Not available	£0,00
# 2	34111-10D00-000 3411110D00000 3411110D00000	SPEEDO CASE CASE, SPEEDOMETER	£77,15
# 3	34210-10D00-000 3421010D00000	TACHOMETER	Not available	£0,00
# 4	34211-10D00-000 3421110D00000	TACHO CASE CASE, TACHOMETER	Not available	£0,00
# 5	34183-10D10-000 3418310D10000 3418310D10000	SCREW SCREW, METER	Not available	£0,00
# 6	36380-10D00-000 3638010D00000 3638010D00000	BOX, PILOT	Not available	£0,00
# 6	36380-10D90-000 3638010D90000 3638010D90000	P BOX BOX, PILOT	Not available	£0,00
# 7	36393-10D00-000 3639310D00000 3639310D00000	UPPER CASE CASE, UPPER	Not available	£0,00
# 8	36381-10D00-000 3638110D00000 3638110D00000	INNER CASE CASE, INNER	Not available	£0,00
# 9	36300-10830-000 3630010830000	LENS SET LENS SET, PILOT	Not available	£0,00
# 10	03112-04129-000 03111-0412A-000 0311204129000	.SCREW	£1,39
# 11	34170-10D00-000 3417010D00000 3417010D00000	REORDER ROBINSONS SOCKET	Not available	£0,00
# 12	36383-10D00-000 3638310D00000 3638310D00000	REORDER ROBINSONS CASE, LOWER	Not available	£0,00
# 13	03111-14165-000 03111-14163-000 0311114165000	SCREW	£2,77
# 14	34199-10D00-000 07130-0520B-000 3419910D00000	BOLT	£4,16
# 15	34118-10D00-000 3411810D00000 3411810D00000	PLATE	Not available	£0,00
# 16	09471-12082-000 0947112082000 0947112082000	BULB BULB (12V, 3.4W)	£7,70
# 17	09471-12085-000 0947112085000 0947112085000	BULB (12V3W, WB371, T7) BULB (12V, 3W)	£4,63
# 18	09471-12100-000 0947112100000 0947112100000	BULB BULB (12V, 1.7W)	£1,54
# 19	34950-11D00-000 3495011D00000 3495011D00000	REORDER ROBINSONS BRACKET, METER	Not available	£0,00
# 19	34950-33D90-000 3495033D90000 3495033D90000	BRACKET, METER	Not available	£0,00
# 20	01107-06305-000 01500-0630A-000 0110706305000	BOLT	£3,52
# 20	01107-06307-000 01500-06307-000 0110706307000	REORDER ROBINSONS BOLT, RH	£3,43
# 21	09160-06020-000 09160-06066-000 0916006020000	WASHER .WASHER (6.5201.6)	£2,59
# 21	09160-06102-000 09160-06088-000 0916006102000	WASHER WASHER (6.5X20X1.6)	£2,12
# 22	09180-06094-000 09180-06251-000 0918006094000	SPACER SPACER (6.1X9X15.5)	£2,69
# 23	09320-09040-000 0932009040000 0932009040000	CUSHION	£4,76
# 24	08319-31055-000 08319-3105A-000 0831931055000	NUT	£4,99
# 25	34161-10D02-000 3416110D02000 3416110D02000	REORDER ROBINSONS CUSHION, PILOT LAMP	Not available	£0,00
# 26	34910-11D01-000 3491011D01000	SPEEDO CABLE ASSY CABLE ASSY, SPEEDOMETER	Not available	£0,00
# 27	34910-10D01-000 34910-33D02-000 3491010D01000	CABLE ASSY, SPEEDOMETER	£62,50
# 28	34910-33D00-000 34910-33D02-000 3491033D00000	CABLE ASSY, SPEEDOMETER	£62,50
# 29	02112-05164-000 02112-0516B-000 0211205164000	SCREW	£2,98
# 30	34938-10D00-000 34938-10D0V-000 3493810D00000	CLAMP, SPEEDOMETER CABLE	£3,83
# 31	34938-10D10-000 34938-10D1V-000 3493810D10000	GUIDE CLAMP, SPEEDOMETER CABLE	£24,19
# 32	01114-06125-000 01550-0612B-000 0111406125000	SCREW AIR CLEANER BOLT	£3,22
# 32	01117-06128-000 01550-06207-000 0111706128000	BOLT DISCONTINUED	£3,05
# 33	34938-11D00-000 3493811D00000 3493811D00000	REORDER ROBINSONS CLAMP, SPEEDOMETER CABLE	£12,65
# 34	09103-10195-000 0910310195000 0910310195000	BOLT BOLT (10X12)	Not available	£0,00

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the SPEEDOMETER of your Suzuki of BANDIT. Let us know if you have any questions.
