TAIL LIGHT FOR SUZUKI DR-Z 400 2009

WIRING HARNESS

Item numbers

LAMP ASSY, RR COMB

35710-13E01-000

35710-13E02-000

£282,18

Unit Price Incl. Tax

LENS

35712-13E00-000 3571213E00000

£32,60

Unit Price Incl. Tax

GASKET

35713-13E00-000 3571313E00000

£7,57

Unit Price Incl. Tax

GASKET

35713-32E00-000 3571332E00000

£10,19

Unit Price Incl. Tax

CONJ PORTALAMPARAS Y CABLE
SOCKET & CORD

35718-13E00-000 3571813E00000

£46,46

Unit Price Incl. Tax

BULB (12V, 21/5W)

09471-12083-000 0947112083000

£8,78

Unit Price Incl. Tax

SCREW

03211-0412A-000 032110412A000

£2,28

Unit Price Incl. Tax

WASHER
WASHER (6.5X20X1.6)

09160-06066-000 0916006066000

£2,59

Unit Price Incl. Tax

SPACER
SPACER (6.5X9X12.5)

09180-06267-000 0918006267000

£5,41

Unit Price Incl. Tax

CUSHION

09320-09016-000 0932009016000

Not available

CUSHION

09329-02002-000 0932902002000

Not available

SCREW

02112-0620B-000 021120620B000

£2,98

Unit Price Incl. Tax

LAMP ASSY LICENSE

35910-29E00-000

Not available

LENS, LICENSE

35912-29E00-000 3591229E00000

£12,29

Unit Price Incl. Tax

COVER, LENS

35917-29E00-000 3591729E00000

£19,06

Unit Price Incl. Tax

BULB (12V, 5W)

09471-12140-000 0947112140000

£2,45

Unit Price Incl. Tax

SCREW

03511-0420B-000 035110420B000

£2,81

Unit Price Incl. Tax

GASKET, LICENSE LAMP

35928-29E11-000 3592829E11000

£22,84

Unit Price Incl. Tax

WASHER
WASHER (5.5X16X1.20)

09160-05043-000 0916005043000

£3,52

Unit Price Incl. Tax

SPACER
SPACER (6.5X9X6.5)

09180-06257-000 0918006257000

£3,64

Unit Price Incl. Tax

SCREW

03511-0516B-000 035110516B000

£2,83

Unit Price Incl. Tax

LICENSE PLATE BRKT.
BRACKET, LICENSE PLATE

35927-00A10-000 3592700A10000

£18,56

Unit Price Incl. Tax

WASHER
WASHER (6.5X18X1.6)

09160-06109-000 0916006109000

£2,59

Unit Price Incl. Tax

SCREW

02142-0616B-000 021420616B000

£2,84

Unit Price Incl. Tax

NUT RECT BRKT
NUT

08316-1006B-000 083161006B000

£3,96

Unit Price Incl. Tax

REAR REFLECTOR
REFLECTOR ASSY, REAR

35970-24D60-000 3597024D60000

£41,51

Unit Price Incl. Tax

NUT

08316-1005B-000 083161005B000

£3,42

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
