CARBURETOR (MODEL L E41 / MODEL K E6 E.NO.211605~) REFER TO FIG.5C (B-14) FOR MODEL M/R

CARBURETOR (MODEL M / R) FOR SUZUKI AD 50 1994

AIR FILTER (MODEL L E41 ~E.NO.211604) REFER TO FIG.6A (C-3) FOR MODEL K E6 %E.NO.211604

(1) 13430-29C50-000

ELEMENT ASSY, THERMO

(2) 13401-29C50-000

THERMO ELEMENT ASSY
ELEMENT ASSY, THERMO

(2) 13401-41D31-000

THERMO ELEMENT ASSY
ELEMENT ASSY, THERMO

(3) 13278-39C60-000

O RING

(4) 02112-3416B-000

SCREW IAC VALVE
SCREW

(5) 13601-04228-000

SCREW

(6) 13511-29C50-000

JOINT

(7) 13394-40D00-000

E RING
.CLIP, NEEDLE

(8) 13615-09400-000

WASHER

(9) 13383-29C50-000

NEEDLE,JET
NEEDLE, JET (3L30-3)

(9) 13383-35440-000

NEEDLE, JET (3L19-2)

(10) 13551-29C50-000

VALVE, PISTON

(11) 09494-00714-000

JET
JET, NEEDLE (E-3)

(11) 09494-00747-000

JET, NEEDLE (E-1)

(12) 09491-57005-000

JET, MAIN (57.5)

(13) 09492-20023-000

PILOT JET
JET, PILOT (20)

(14) 13370-40D00-000

NEEDLE VALVE ASSY
VALVE ASSY, NEEDLE

(14) 13370-02421-000

NEEDLE VALVE ASSY
VALVE ASSY, NEEDLE

(15) 13250-29C50-000

REORDER ROBINSONS
FLOAT

(16) 13254-29C50-000

REORDER ROBINSONS
PIN, FLOAT

(17) 13258-29C50-000

GASKET

(18) 02112-3516A-000

SCREW

(19) 13247-25E00-000

REORDER ROBINSONS
SCREW, DRAIN

(20) 13278-02340-000

O RING

(21) 13681-04011-000

CAP
CAP, CARBURETOR

(22) 13373-46710-000

PLATE

(23) 02112-0306B-000

SCREW

(24) 13543-09400-000

SPRING

(25) 13540-25E00-000

THROTTLE LEVER SET
LEVER, THROTTLE

(26) 02112-3412B-000

SCREW

(27) 13550-29C50-000

SHAFT ASSY, THROTTLE

(28) 13557-09400-000

PLATE

(29) 13574-29C50-000

RING

(30) 13651-51011-000

SEAL

(31) 13573-25E10-000

SPRING

(32) 13572-29C50-000

RING

(33) 13569-29C50-000

CABLE GUIDE
GUIDE, CABLE

(34) 13484-29C50-000

REORDER ROBINSONS
COVER, THROTTLE

(35) 13237-29C50-000

GASKET

(36) 02112-7410B-000

SCREW (4X10)
.SCREW

(37) 13268-35010-000

SPRING

(38) 13291-35010-000

WASHER

(39) 13295-33010-000

O RING

(40) 13267-25E00-000

ADJUSTER

(41) 13278-29C50-000

O RING

(42) 09493-22005-000

PILOT AIR JET
JET, AIR (1.1)

(43) 13684-29C50-000

HOSE
HOSE (3.5X6.5X750)

(44) 09352-30504-600

HOSE
.HOSE, OVER FLOW (3X5X300->200)

(45) 13279-37B30-000

SCREW AIR
SCREW, AIR (1 1/4)

(46) 13268-48700-000

SPRING

(47) 13606-47A00-000

WASHER

(48) 13295-29901-000

O RING,PILOT AIR SCREW
O RING

(49) 09250-06005-000

CAP
CAP, HEATER BOSS

(50) 13650-25E01-000

CARBURETOR HEATER
HEATER, CARBURETOR

(51) 13655-25E00-000

CARB.HEATER THERMO SWITCH
SWITCH, THERMO

(52) 36852-29C10-000

WIRE, CARBURETOR HEATER LEAD

(53) 36852-39C00-000

WIRE, CARBURETOR HEATER LEAD

99x

(99x) 13200-29C50-000

CARBURETOR ASSY

(99x) 13200-29C51-000

CARBURETOR ASSY

(99x) 13200-29C70-000

CARBURETOR ASSY

(99x) 13200-29C80-000

CARBURETOR ASSY

	Part number	Description	Qty
# 1	13430-29C50-000 1343029C50000 1343029C50000	ELEMENT ASSY, THERMO	Not available	£0,00
# 2	13401-29C50-000 1340129C50000 1340129C50000	THERMO ELEMENT ASSY ELEMENT ASSY, THERMO	£304,04
# 2	13401-41D30-000 1340141D30000	THERMO ELEMENT ASSY ELEMENT ASSY, THERMO	Not available	£0,00
# 3	13278-39C60-000 1327839C60000 1327839C60000	O RING	£9,54
# 4	02112-34163-000 02112-3416B-000 0211234163000	SCREW IAC VALVE SCREW	£2,81
# 5	13601-04228-000 1360104228000 1360104228000	SCREW	£5,51
# 6	13511-29C50-000 1351129C50000 1351129C50000	JOINT	£9,58
# 7	13394-12110-000 13394-40D00-000 1339412110000	E RING .CLIP, NEEDLE	£6,18
# 8	13615-09400-000 1361509400000 1361509400000	WASHER	Not available	£0,00
# 9	13383-29C50-000 1338329C50000 1338329C50000	NEEDLE, JET NEEDLE, JET (3L30-3)	Not available	£0,00
# 9	13383-35440-000 1338335440000 1338335440000	NEEDLE, JET (3L19-2)	Not available	£0,00
# 10	13551-29C50-000 1355129C50000 1355129C50000	VALVE, PISTON	Not available	£0,00
# 11	09494-00714-000 0949400714000 0949400714000	JET JET, NEEDLE (E-3)	Not available	£0,00
# 11	09494-00747-000 0949400747000 0949400747000	JET, NEEDLE (E-1)	Not available	£0,00
# 12	09491-57005-000 0949157005000 0949157005000	JET, MAIN (57.5)	£23,22
# 13	09492-20023-000 0949220023000 0949220023000	PILOT JET JET, PILOT (20)	£26,77
# 14	13370-29C50-000 13370-40D00-000 1337029C50000	NEEDLE VALVE ASSY VALVE ASSY, NEEDLE	£90,76
# 14	13370-02421-000 1337002421000 1337002421000	NEEDLE VALVE ASSY VALVE ASSY, NEEDLE	Not available	£0,00
# 15	13250-29C50-000 1325029C50000 1325029C50000	REORDER ROBINSONS FLOAT	£49,20
# 16	13254-29C50-000 1325429C50000 1325429C50000	REORDER ROBINSONS PIN, FLOAT	£7,37
# 17	13258-29C50-000 1325829C50000 1325829C50000	GASKET	£15,02
# 18	02112-35163-000 02112-3516A-000 0211235163000	SCREW	£2,59
# 19	13247-29C50-000 13247-25E00-000 1324729C50000	REORDER ROBINSONS SCREW, DRAIN	£35,76
# 20	13278-02340-000 1327802340000 1327802340000	O RING	£1,43
# 21	13681-04010-000 13681-04011-000 1368104010000	CAP CAP, CARBURETOR	£4,91
# 22	13373-46710-000 1337346710000 1337346710000	PLATE	£8,18
# 23	02112-03063-000 02112-0306B-000 0211203063000	SCREW	£2,02
# 24	13543-09400-000 1354309400000 1354309400000	SPRING	£6,38
# 25	13541-29C50-000 13540-25E00-000 1354129C50000	THROTTLE LEVER SET LEVER, THROTTLE	£41,83
# 26	02112-34123-000 02112-3412B-000 0211234123000	SCREW	£3,29
# 27	13550-29C50-000 1355029C50000 1355029C50000	SHAFT ASSY, THROTTLE	Not available	£0,00
# 28	13557-09400-000 1355709400000 1355709400000	PLATE	£10,87
# 29	13574-29C50-000 1357429C50000 1357429C50000	RING	£6,38
# 30	13651-51010-000 13651-51011-000 1365151010000	SEAL	£3,46
# 31	13573-29C50-000 13573-25E10-000 1357329C50000	SPRING	£19,18
# 32	13572-29C50-000 1357229C50000 1357229C50000	RING	Not available	£0,00
# 33	13569-29C50-000 1356929C50000 1356929C50000	CABLE GUIDE GUIDE, CABLE	£12,24
# 34	13484-29C50-000 1348429C50000 1348429C50000	REORDER ROBINSONS COVER, THROTTLE	Not available	£0,00
# 35	13237-29C50-000 1323729C50000 1323729C50000	GASKET	£14,44
# 36	02112-74106-000 02112-7410B-000 0211274106000	SCREW (4X10) .SCREW	£3,20
# 37	13268-35010-000 1326835010000 1326835010000	SPRING	£7,37
# 38	13291-35010-000 1329135010000 1329135010000	WASHER	£6,11
# 39	13295-33010-000 1329533010000 1329533010000	O RING	£7,37
# 40	13267-29C50-000 13267-25E00-000 1326729C50000	ADJUSTER	£19,18
# 41	13278-29C50-000 1327829C50000 1327829C50000	O RING	£8,59
# 42	09493-22005-000 0949322005000 0949322005000	PILOT AIR JET JET, AIR (1.1)	£24,24
# 43	13684-29C50-000 1368429C50000 1368429C50000	HOSE HOSE (3.5X6.5X750)	Not available	£0,00
# 44	13683-36A00-000 09352-30504-600 1368336A00000	HOSE .HOSE, OVER FLOW (3X5X300->200)	£6,43
# 45	13279-37B30-000 1327937B30000 1327937B30000	SCREW AIR SCREW, AIR (1 1/4)	£17,29
# 46	13268-48700-000 1326848700000 1326848700000	SPRING	£7,39
# 47	13606-47A00-000 1360647A00000 1360647A00000	WASHER	£4,40
# 48	13295-29900-000 13295-29901-000 1329529900000	O RING, PILOT AIR SCREW O RING	£4,48
# 49	09250-06001-000 09250-06005-000 0925006001000	CAP CAP, HEATER BOSS	£2,18
# 50	13692-36C00-000 13650-25E01-000 1369236C00000	CARBURETOR HEATER HEATER, CARBURETOR	£21,44
# 51	13694-36C01-000 13655-25E00-000 1369436C01000	CARB.HEATER THERMO SWITCH SWITCH, THERMO	£87,30
# 52	36852-29C10-000 3685229C10000 3685229C10000	WIRE, CARBURETOR HEATER LEAD	Not available	£0,00
# 53	36852-39C00-000 3685239C00000 3685239C00000	WIRE, CARBURETOR HEATER LEAD	Not available	£0,00
# 99x	13200-29C50-000 1320029C50000 1320029C50000	CARBURETOR ASSY	Not available	£0,00
# 99x	13200-29C51-000 1320029C51000 1320029C51000	CARBURETOR ASSY	Not available	£0,00
# 99x	13200-29C70-000 1320029C70000 1320029C70000	CARBURETOR ASSY	Not available	£0,00
# 99x	13200-29C80-000 1320029C80000 1320029C80000	CARBURETOR ASSY	Not available	£0,00

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
