FAIRING FOR SUZUKI ADDRESS 50 1992

LEG SHIELD

(1) 47100-40D50-019

COVER,SIDE REAR
COVER ASSY, SIDE RH (BLACK)

(1) 47100-40D50-02X

COVER ASSY, SIDE RH (BLACK)

(1) 47100-40D50-19A

COVER ASSY, SIDE RH (RED)

(2) 47311-40D10-019

LID,FUEL FILLER
LID, FUEL FILLER (BLACK)

(2) 47311-40D10-19A

LID, FUEL FILLER (RED)

(3) 68131-40D30-A7Y

EMBLEM
EMBLEM, FRAME COVER

(3) 68131-40D30-A7Z

EMBLEM, FRAME COVER

(3) 68131-40D30-D6W

EMBLEM, FRAME COVER

(4) 47191-40D00-19A

SPOILER, RH (RED)

(4) 47191-40D00-1HU

SPOILER, RH (PURPLE)

(4) 47191-40D00-28C

SPOILER, RH (GRAY)

(5) 47161-40D10-000

CUSHION,SPOILER(6X25X2)
CUSHION, SPOILER

(5) 47161-40D10-000

CUSHION,SPOILER(6X25X2)
CUSHION, SPOILER

(6) 03541-0410A-000

SCREW

(7) 47312-40D10-000

HINGE, FUEL LID

(8) 03541-0512B-000

SCREW

(9) 47313-40D11-000

PLATE, FUEL LID

(10) 03541-0410A-000

SCREW

(11) 47314-40D00-000

HOOK, FUEL LID

(12) 03541-0512B-000

SCREW

(13) 47315-40D00-000

SPRING, FUEL LID RETURN

(14) 47920-40D00-000

BRACKET, FUEL LID LOCK

(15) 03541-0510A-000

SCREW

(16) 76520-40D00-000

OPENNER ASSY, FUEL LID

(17) 08310-0010A-000

NUT

(18) 47131-40D00-0LS

COVER, SIDE LOWER RH (CHARCOAL)

(18) 47131-40D00-291

COVER,SIDE REAR
COVER, SIDE LOWER RH (BLACK)

(19) 47211-40D20-019

COVER, SIDE LH (BLACK)

(19) 47211-40D20-19A

COVER, SIDE LH (RED)

(20) 09320-08049-000

CUSHION

(21) 02142-0512A-000

SCREW

(22) 63191-25C00-000

CUSHION
CUSHION, FUEL TANK

(23) 68131-40D30-A7Y

EMBLEM
EMBLEM, FRAME COVER

(23) 68131-40D30-A7Z

EMBLEM, FRAME COVER

(23) 68131-40D30-D6W

EMBLEM, FRAME COVER

(24) 47231-40D00-0LS

COVER, SIDE LOWER LH (CHARCOAL)

(24) 47231-40D00-291

COVER, SIDE LOWER LH (BLACK)

(25) 47291-40D00-19A

SPOILER, LH (RED)

(25) 47291-40D00-1HU

SPOILER, LH (PURPLE)

(25) 47291-40D00-28C

SPOILER, LH (GRAY)

(26) 47351-40D00-0LS

PLUG, COVER SIDE (CHARCOAL)

(26) 47351-40D00-291

PLUG, COVER SIDE (BLACK)

(27) 47490-40D00-000

BRACKET, SPOILER

(28) 09125-06036-000

SCREW

(28) 09125-06036-000

SCREW

(29) 02142-05127-000

SCREW

(30) 09169-05013-000

WASHER

(31) 03241-0516A-000

SCREW
SCREW, CENTER PANEL (5X16)

(32) 09148-05020-000

NUT

(33) 03541-0412A-000

SCREW,REAR
SCREW

(34) 09148-04024-000

NUT

(35) 03241-1516A-000

SCREW SEAT TAIL COVER
SCREW

(36) 09148-05013-000

NUT
ASHTRAY GUIDE NUT

(37) 02142-1612B-000

SCREW

(38) 47321-40D00-0LS

COVER, REAR (CHARCOAL)

(38) 47321-40D00-291

COVER, REAR (BLACK)

(39) 03241-0516A-000

SCREW
SCREW, CENTER PANEL (5X16)

(40) 09148-05020-000

NUT

(41) 03241-0512A-000

SCREW
SCREW, PANEL LOWER (5X12)

	Part number	Description	Qty
# 1	47100-40D50-019 4710040D50019 4710040D50019	COVER, SIDE REAR COVER ASSY, SIDE RH (BLACK)	Not available	£0,00
# 1	47100-40D50-02X 4710040D5002X 4710040D5002X	COVER ASSY, SIDE RH (BLACK)	Not available	£0,00
# 1	47100-40D50-19A 4710040D5019A 4710040D5019A	COVER ASSY, SIDE RH (RED)	Not available	£0,00
# 2	47311-40D10-019 4731140D10019 4731140D10019	LID, FUEL FILLER LID, FUEL FILLER (BLACK)	Not available	£0,00
# 2	47311-40D10-19A 4731140D1019A 4731140D1019A	LID, FUEL FILLER (RED)	Not available	£0,00
# 3	68131-40D30-A7Y 6813140D30A7Y 6813140D30A7Y	EMBLEM EMBLEM, FRAME COVER	Not available	£0,00
# 3	68131-40D30-A7Z 6813140D30A7Z 6813140D30A7Z	EMBLEM, FRAME COVER	Not available	£0,00
# 3	68131-40D30-D6W 6813140D30D6W 6813140D30D6W	EMBLEM, FRAME COVER	Not available	£0,00
# 4	47191-40D00-19A 4719140D0019A 4719140D0019A	SPOILER, RH (RED)	Not available	£0,00
# 4	47191-40D00-1HU 4719140D001HU 4719140D001HU	SPOILER, RH (PURPLE)	Not available	£0,00
# 4	47191-40D00-28C 4719140D0028C 4719140D0028C	SPOILER, RH (GRAY)	Not available	£0,00
# 5	47161-40D10-000 4716140D10000 4716140D10000	CUSHION, SPOILER(6X25X2) CUSHION, SPOILER	£1,76
# 6	03541-04103-000 03541-0410A-000 0354104103000	SCREW	£1,80
# 7	47312-40D10-000 4731240D10000 4731240D10000	HINGE, FUEL LID	Not available	£0,00
# 8	03541-05123-000 03541-0512B-000 0354105123000	SCREW	£2,21
# 9	47313-40D11-000 4731340D11000 4731340D11000	PLATE, FUEL LID	Not available	£0,00
# 10	03541-04103-000 03541-0410A-000 0354104103000	SCREW	£1,80
# 11	47314-40D00-000 4731440D00000 4731440D00000	HOOK, FUEL LID	Not available	£0,00
# 12	03541-05123-000 03541-0512B-000 0354105123000	SCREW	£2,21
# 13	47315-40D00-000 4731540D00000 4731540D00000	SPRING, FUEL LID RETURN	Not available	£0,00
# 14	47920-40D00-000 4792040D00000 4792040D00000	BRACKET, FUEL LID LOCK	Not available	£0,00
# 15	03541-05103-000 03541-0510A-000 0354105103000	SCREW	£1,92
# 16	76520-40D00-000 7652040D00000 7652040D00000	OPENNER ASSY, FUEL LID	Not available	£0,00
# 17	08310-00103-000 08310-0010A-000 0831000103000	NUT	£1,69
# 18	47131-40D00-0LS 4713140D000LS 4713140D000LS	COVER, SIDE LOWER RH (CHARCOAL)	Not available	£0,00
# 18	47131-40D00-291 4713140D00291 4713140D00291	COVER, SIDE REAR COVER, SIDE LOWER RH (BLACK)	Not available	£0,00
# 19	47211-40D20-019 4721140D20019 4721140D20019	COVER, SIDE LH (BLACK)	Not available	£0,00
# 19	47211-40D20-19A 4721140D2019A 4721140D2019A	COVER, SIDE LH (RED)	Not available	£0,00
# 20	09320-08049-000 0932008049000 0932008049000	CUSHION	£6,47
# 21	02142-15127-000 0214215127000	SCREW	Not available	£0,00
# 22	44281-29C00-000 63191-25C00-000 4428129C00000	CUSHION CUSHION, FUEL TANK	£4,54
# 23	68131-40D30-A7Y 6813140D30A7Y 6813140D30A7Y	EMBLEM EMBLEM, FRAME COVER	Not available	£0,00
# 23	68131-40D30-A7Z 6813140D30A7Z 6813140D30A7Z	EMBLEM, FRAME COVER	Not available	£0,00
# 23	68131-40D30-D6W 6813140D30D6W 6813140D30D6W	EMBLEM, FRAME COVER	Not available	£0,00
# 24	47231-40D00-0LS 4723140D000LS 4723140D000LS	COVER, SIDE LOWER LH (CHARCOAL)	Not available	£0,00
# 24	47231-40D00-291 4723140D00291 4723140D00291	COVER, SIDE LOWER LH (BLACK)	Not available	£0,00
# 25	47291-40D00-19A 4729140D0019A 4729140D0019A	SPOILER, LH (RED)	Not available	£0,00
# 25	47291-40D00-1HU 4729140D001HU 4729140D001HU	SPOILER, LH (PURPLE)	Not available	£0,00
# 25	47291-40D00-28C 4729140D0028C 4729140D0028C	SPOILER, LH (GRAY)	Not available	£0,00
# 26	47351-40D00-0LS 4735140D000LS 4735140D000LS	PLUG, COVER SIDE (CHARCOAL)	Not available	£0,00
# 26	47351-40D00-291 4735140D00291 4735140D00291	PLUG, COVER SIDE (BLACK)	Not available	£0,00
# 27	47490-40D00-000 4749040D00000 4749040D00000	BRACKET, SPOILER	Not available	£0,00
# 28	09125-06036-000 0912506036000 0912506036000	SCREW	£1,70
# 29	02142-05127-000 0214205127000 0214205127000	SCREW	£2,59
# 30	09169-05013-000 0916905013000 0916905013000	WASHER	£5,62
# 31	03241-05163-000 03241-0516A-000 0324105163000	SCREW SCREW, CENTER PANEL (5X16)	£1,55
# 32	09148-05020-000 0914805020000 0914805020000	NUT	£2,75
# 33	03541-04123-000 03541-0412A-000 0354104123000	SCREW, REAR SCREW	£1,96
# 34	09148-04024-000 0914804024000 0914804024000	NUT	£2,62
# 35	03241-15163-000 03241-1516A-000 0324115163000	SCREW SEAT TAIL COVER SCREW	£3,29
# 36	09148-05004-000 09148-05013-000 0914805004000	NUT ASHTRAY GUIDE NUT	£2,28
# 37	02142-16123-000 02142-1612B-000 0214216123000	SCREW	£3,64
# 38	47321-40D00-0LS 4732140D000LS 4732140D000LS	COVER, REAR (CHARCOAL)	Not available	£0,00
# 38	47321-40D00-291 4732140D00291 4732140D00291	COVER, REAR (BLACK)	Not available	£0,00
# 39	03241-05163-000 03241-0516A-000 0324105163000	SCREW SCREW, CENTER PANEL (5X16)	£1,55
# 40	09148-05020-000 0914805020000 0914805020000	NUT	£2,75
# 41	03241-05123-000 03241-0512A-000 0324105123000	SCREW SCREW, PANEL LOWER (5X12)	£1,56

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the FAIRING of your Suzuki of ADDRESS. Let us know if you have any questions.
