WIRING HARNESS FOR SUZUKI ZILLION 50 2000

SWITCH ASSY

(1) 36610-06EA0-000

HARNESS WIRING UX50
HARNESS WIRING

(1) 36610-06EB0-000

HARNESS WIRING

(1A) 09481-10001-000

FUSE 10A
FUSE

(2) DTP00-30055-140

TUBE, WIRING

(3) 09407-14401-000

CLAMP
CLAMP (L:95)

(3) 09407-25401-000

CLAMP
CLAMP (L:235)

(3) 09407-14403-000

CLAMP
CLAMP (L:125)

(3) 09407-18402-000

CLAMP
CLAMP (L:165)

(4) 36210-35EA0-000

HELMET BOX LAMP ASSY
LAMP ASSY, TRUNK BOX

(5) 36212-39C00-000

LENS

(6) 36210-29C11-000

HELMET BOX LAMP ASSY
SOCKET

(7) 09471-12108-000

BULB (12V1.7W,T6.5)
BULV (13.5V,2W)

(8) 03541-0412A-000

SCREW,REAR
SCREW

(9) 37100-06E00-000

LOCK ASSY, STEERING

(10) 37146-09EF0-000

STEERING LOCK KEYS
KEY, BLANK

(11) 37155-06E00-000

CUP, IGNITION SWITCH

(12) 09689-AF172-000

BOLT, LOCK ASSY

(13) 38500-22F00-000

HORN ASSY

(14) 01550-0816B-000

BOLT
BOLT,HORN

(15) 02112-0610B-000

SCREW CENTER SHAFT
BOLT

(16) 36851-06F00-000

CARB. HEATER LEAD (OPT.)
WIRE, CARB. HEATER LEAD

	Part number	Description	Qty
# 1A	09481-10001-000 0948110001000 0948110001000	FUSE 10A FUSE	£2,11
# 1	36610-06EA0-000 3661006EA0000 3661006EA0000	HARNESS WIRING UX50 HARNESS WIRING	Not available	£0,00
# 1	36610-06EB0-000 3661006EB0000 3661006EB0000	HARNESS WIRING	Not available	£0,00
# 2	DTP00-30055-140 DTP0030055140 DTP0030055140	TUBE, WIRING	Not available	£0,00
# 3	09407-14401-000 0940714401000 0940714401000	CLAMP CLAMP (L:95)	£4,85
# 3	09407-14403-000 0940714403000 0940714403000	CLAMP CLAMP (L:125)	£2,84
# 3	09407-18402-000 0940718402000 0940718402000	CLAMP CLAMP (L:165)	£1,79
# 3	09407-25401-000 0940725401000 0940725401000	CLAMP CLAMP (L:235)	£3,23
# 4	36210-39C00-X00 36210-35EA0-000 3621039C00X00	HELMET BOX LAMP ASSY LAMP ASSY, TRUNK BOX	£54,82
# 5	36212-39C00-000 3621239C00000 3621239C00000	LENS	£10,57
# 6	36219-39C00-000 3621939C00000	HELMET BOX LAMP ASSY SOCKET	Not available	£0,00
# 7	09471-12118-000 09471-12108-000 0947112118000	BULB (12V1.7W, T6.5) BULV (13.5V, 2W)	£1,69
# 8	03541-04123-000 03541-0412A-000 0354104123000	SCREW, REAR SCREW	£1,96
# 9	37100-06E00-000 3710006E00000 3710006E00000	LOCK ASSY, STEERING	£183,85
# 10	37146-09EF0-000 3714609EF0000 3714609EF0000	STEERING LOCK KEYS KEY, BLANK	Not available	£0,00
# 11	37155-06E00-000 3715506E00000 3715506E00000	CUP, IGNITION SWITCH	Not available	£0,00
# 12	09689-AF172-000 09689AF172000 09689AF172000	BOLT, LOCK ASSY	£5,03
# 13	38500-22F00-000 3850022F00000 3850022F00000	HORN ASSY	Not available	£0,00
# 14	01550-08163-000 01550-0816B-000 0155008163000	BOLT BOLT, HORN	£2,30
# 15	D2116-06108-000 02112-0610B-000 D211606108000	SCREW CENTER SHAFT BOLT	£2,44
# 16	36851-06F00-000 3685106F00000 3685106F00000	CARB. HEATER LEAD (OPT.) WIRE, CARB. HEATER LEAD	£5,93

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
