FUEL TANK (MODEL Y)

FAIRING (MODEL V) FOR SUZUKI GS-E 500 1997

FAIRING (MODEL W) REFER TO FIG.35B(F-12) FOR MODEL X

Item numbers

FRAME COVER
COVER, FRAME RH (RED)

47110-01DF0-19A 4711001DF019A

Not available

FRAME COVER
COVER, FRAME RH (BLUE)

47110-01DF0-1LF 4711001DF01LF

Not available

FRAME COVER
COVER, FRAME RH (BLACK)

47110-01DF0-33J 4711001DF033J

Not available

FRAME COVER
COVER, FRAME RH (GREEN)

47110-01DF0-Y0V 4711001DF0Y0V

Not available

TAPE FRAME COVER RH
TAPE, RH

68135-01D10-Y1P 6813501D10Y1P

Not available

TAPE FRAME COVER RH
TAPE, RH

68135-01D10-Y1R 6813501D10Y1R

Not available

TAPE, RH

68135-01D10-Y1S 6813501D10Y1S

Not available

TAPE, RH

68135-01D10-Y1T 6813501D10Y1T

Not available

REORDER ROBINSONS
PROTECTOR, RH

47119-01D00-000 4711901D00000

Not available

L.H. FRAME COVER COMP.
COVER, FRAME LH (RED)

47210-01DF0-19A 4721001DF019A

Not available

L.H. FRAME COVER COMP.
COVER, FRAME LH (BLUE)

47210-01DF0-1LF 4721001DF01LF

Not available

COVER, FRAME LH (BLACK)

47210-01DF0-33J 4721001DF033J

Not available

L.H. FRAME COVER COMP.
COVER, FRAME LH (GREEN)

47210-01DF0-Y0V 4721001DF0Y0V

Not available

TAPE FRAME COVER LH
TAPE, LH

68145-01D10-Y1P 6814501D10Y1P

Not available

TAPE FRAME COVER LH
TAPE, LH

68145-01D10-Y1R 6814501D10Y1R

Not available

TAPE FRAME COVER LH
TAPE, LH

68145-01D10-Y1S 6814501D10Y1S

Not available

TAPE FRAME COVER LH
TAPE, LH

68145-01D10-Y1T 6814501D10Y1T

Not available

REORDER ROBINSONS
PROTECTOR, LH

47219-01D00-000 4721901D00000

Not available

BOLT

09116-06010-000

01107-06208-000

£3,24

Unit Price Incl. Tax

SPACER

09180-06263-000 0918006263000

£2,69

Unit Price Incl. Tax

CUSHION

09320-09016-000 0932009016000

Not available

CENTRE COVER RED
COVER, CENTER (RED)

47215-01D00-19A 4721501D0019A

Not available

PLATE

47215-01D00-1LF

Not available

COVER FRAME CENTRE
COVER, CENTER (BLACK)

47215-01D00-33J 4721501D0033J

Not available

CENTRE FRAME COVER
COVER, CENTER (GREEN)

47215-01D00-Y0V 4721501D00Y0V

Not available

SCREW

03242-05123-000

03242-0512A-000

£1,56

Unit Price Incl. Tax

WASHER

09161-05017-000 0916105017000

Not available

NUT

09148-05004-000

09148-05013-000

£2,28

Unit Price Incl. Tax

CUSHION

09320-08018-000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the FAIRING (MODEL V) of your Suzuki GSE 500 of GS-E. Let us know if you have any questions.
