CARBURETOR REFER TO FIG.12A(C-9) FOR MODEL W/X/Y E4

CARBURETOR (MODEL W / X / Y E4) FOR SUZUKI GS-E 500 2000

AIR FILTER

Item numbers

CARBURETOR ASSY, LH

13201-01DB0-000 1320101DB0000

Not available

CARBURETOR ASSY, LH

13201-01DC1-000 1320101DC1000

Not available

CARBURETOR ASSY, RH

13202-01DB0-000 1320201DB0000

£579,36

Unit Price Incl. Tax

CARBURETOR ASSY, RH

13202-01DC1-000 1320201DC1000

Not available

SPRING

13573-01DB0-000 1357301DB0000

Not available

DIAPHRAGM

13507-17C01-000 1350717C01000

Not available

PISTON VALVE
VALVE, PISTON

13501-34E00-000 1350134E00000

£110,57

Unit Price Incl. Tax

VALVE, PISTON

13501-01DC0-000 1350101DC0000

Not available

HOLDER

13418-33E00-000 1341833E00000

£12,08

Unit Price Incl. Tax

O RING
O RING (D:1.9, ID:4.8)

09280-05004-000 0928005004000

£4,14

Unit Price Incl. Tax

SPRING

13481-33E00-000 1348133E00000

£7,66

Unit Price Incl. Tax

JET NEEDLE WASHER
WASHER

13382-44030-000 1338244030000

£8,48

Unit Price Incl. Tax

E RING

13394-17E60-000 1339417E60000

£3,50

Unit Price Incl. Tax

13387-33E00-000
RING

13387-33E00-000 1338733E00000

Not available

NEEDLE, JET
NEEDLE, JET (5DH25-55-3)

13383-01DB0-000 1338301DB0000

Not available

JET, NEEDLE (P-5)

09494-00912-000 0949400912000

£58,75

Unit Price Incl. Tax

O RING

13246-43010-000 1324643010000

£4,98

Unit Price Incl. Tax

HOLDER, JET

13385-07F00-000 1338507F00000

£71,16

Unit Price Incl. Tax

MAIN JET
JET, MAIN (130)

09491-26016-000 0949126016000

£20,82

Unit Price Incl. Tax

O RING

13295-29900-000 1329529900000

Not available

WASHER

13291-29900-000 1329129900000

£3,50

Unit Price Incl. Tax

SPRING

13268-48700-000 1326848700000

£9,31

Unit Price Incl. Tax

ADJUSTER (2.0)
ADJUSTER (2 5/8)

13279-33E00-000 1327933E00000

£21,26

Unit Price Incl. Tax

NEEDLE VALVE ASSY.
VALVE ASSY, NEEDLE (1.5)

13370-33E80-000 1337033E80000

£86,66

Unit Price Incl. Tax

02112-04083-000
SCREW

02112-04083-000 0211204083000

Not available

SCREW

13602-05A10-000 1360205A10000

£7,66

Unit Price Incl. Tax

FLOAT
FLOAT ASSY

13250-04F00-000 1325004F00000

£72,35

Unit Price Incl. Tax

FLOAT PIN
PIN, FLOAT

13254-01010-000 1325401010000

£8,20

Unit Price Incl. Tax

JET, PILOT (17.5)

09492-17016-000 0949217016000

£34,90

Unit Price Incl. Tax

POWER JET
JET, MAIN (60)

09491-60010-000 0949160010000

£27,66

Unit Price Incl. Tax

JET, PILOT AIR (170)

09493-34003-000 0949334003000

£33,50

Unit Price Incl. Tax

FL CHAMBER GASKET ASB
GASKET

13258-04F00-000 1325804F00000

£22,25

Unit Price Incl. Tax

SCREW

02112-04107-000 0211204107000

£3,52

Unit Price Incl. Tax

13247-07F00-000
PLUG, DRAIN

13247-07F00-000 1324707F00000

Not available

COVER ASSY, DIAPHRAGM LH

13502-01DB0-000 1350201DB0000

£68,70

Unit Price Incl. Tax

COVER ASSY, DIAPHRAGM RH

13502-01DC0-000 1350201DC0000

£65,29

Unit Price Incl. Tax

PLUNGER ASSY

13411-05300-000 1341105300000

£58,75

Unit Price Incl. Tax

SPRING

13417-26D00-000 1341726D00000

£12,61

Unit Price Incl. Tax

O RING

13278-47090-000 1327847090000

£2,14

Unit Price Incl. Tax

PLUNGER GUIDE SCREW
HOLDER, GUIDE

13418-44080-000 1341844080000

£20,56

Unit Price Incl. Tax

STARTER VALVE CAP
CAP

13682-31210-000 1368231210000

£9,31

Unit Price Incl. Tax

SCREW

02112-05127-000 0211205127000

£3,06

Unit Price Incl. Tax

CAP

13274-84000-000 1327484000000

£4,16

Unit Price Incl. Tax

CLIP

09401-06101-000 0940106101000

£1,91

Unit Price Incl. Tax

ADJUSTER

13267-04F00-000 1326704F00000

£33,10

Unit Price Incl. Tax

SPRING

13271-33C00-000 1327133C00000

£10,58

Unit Price Incl. Tax

HOSE

09355-35755-600 0935535755600

£12,71

Unit Price Incl. Tax

13683-33E50-000
HOSE

13683-33E50-000 1368333E50000

Not available

NIPPLE

13685-04F10-000 1368504F10000

£18,43

Unit Price Incl. Tax

CHECK VALVE
CHECK VALVE ASSY

95569-78040-000 9556978040000

£43,74

Unit Price Incl. Tax

SOLENOID VALVE ASSY.
VALVE ASSY, SOLENOID

18115-70G10-000 1811570G10000

£156,46

Unit Price Incl. Tax

HOSE

13683-01DB0-000 1368301DB0000

£12,78

Unit Price Incl. Tax

HOSE

13684-40C00-000 1368440C00000

£35,24

Unit Price Incl. Tax

HOSE

13683-46D10-000 1368346D10000

£21,31

Unit Price Incl. Tax

HOSE

13683-01DC1-000 1368301DC1000

£31,79

Unit Price Incl. Tax

CLIP

09401-16401-000 0940116401000

£5,77

Unit Price Incl. Tax

CLAMP
CLIP

09408-00033-000 0940800033000

£2,57

Unit Price Incl. Tax

LEVER

13413-01DB0-000 1341301DB0000

Not available

02142-04083-000
SCREW

02142-04083-000 0214204083000

Not available

PACKING

13557-33E00-000 1355733E00000

£7,74

Unit Price Incl. Tax

THROTTLE SENSOR ASSY.
SENSOR ASSY

13550-13D60-000 1355013D60000

Not available

13602-55A00-000
SCREW

13602-55A00-000 1360255A00000

Not available

HOSE

09355-35755-600 0935535755600

£12,71

Unit Price Incl. Tax

HOSE

09355-35755-600 0935535755600

£12,71

Unit Price Incl. Tax

HOSE

09355-35755-600 0935535755600

£12,71

Unit Price Incl. Tax

3 WAY
NIPPLE

09367-04007-000 0936704007000

£7,62

Unit Price Incl. Tax

HOSE

09355-35755-600 0935535755600

£12,71

Unit Price Incl. Tax

ROD

13685-01DC0-000 1368501DC0000

£31,45

Unit Price Incl. Tax

PIPE

13685-01DB0-000 1368501DB0000

£27,58

Unit Price Incl. Tax

13268-96110-000
SPRING

13268-96110-000 1326896110000

Not available

SPRING

13271-44B00-000 1327144B00000

£9,67

Unit Price Incl. Tax

SCREW

13267-44B00-000 1326744B00000

£6,92

Unit Price Incl. Tax

SEAL

13673-44B00-000 1367344B00000

£11,39

Unit Price Incl. Tax

NIPPLE

13685-33EQ0-000 1368533EQ0000

£57,55

Unit Price Incl. Tax

HOSE
HOSE, CONTROL AIR

09355-35755-600 0935535755600

£12,71

Unit Price Incl. Tax

09355-50105-600
HOSE, FUEL COCK VACUUM

09355-50105-600 0935550105600

Not available

VACUUM CHAMBER COMP.
CHAMBER, VACUUM

13715-04F00-000 1371504F00000

£48,73

Unit Price Incl. Tax

01550-06203-000
BOLT

01550-06203-000 0155006203000

Not available

A/CLEANER 2ND. FILTER
FILTER, AIR CLEANER NO.2

18780-32E00-000 1878032E00000

£61,45

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the CARBURETOR (MODEL W/X/Y E4) of your Suzuki GSE 500 of GS-E. Let us know if you have any questions.
