TAIL LIGHT FOR SUZUKI GS-F 500 2009

WIRING HARNESS (GS500H P28, P95) REFER TO FIG. 34 (E- 8) FOR GS500FH P3, P28, P33, P95

Item numbers

LAMP ASSY, RR COMB
LAMP ASSY, REAR COMBINATION

35710-01D30-000 3571001D30000

£216,78

Unit Price Incl. Tax

LENS

35712-01D20-000 3571201D20000

£117,94

Unit Price Incl. Tax

GASKET, LENS

35713-01D20-000 3571301D20000

£20,34

Unit Price Incl. Tax

SCREW

03511-0440B-000 035110440B000

Not available

BULB (12V, 32/3CP)

09471-12204-000 0947112204000

£10,01

Unit Price Incl. Tax

CUSHION (80X20X10)

33652-C01-D10J000

33652-01D10-000

£8,41

Unit Price Incl. Tax

CUSHION UPPER (40X40X38)

33652-C01-D20J000

33652-01D20-000

£8,96

Unit Price Incl. Tax

PROTECTOR 40X120X6 GS500

33652-C09-400J000

33652-06C00-000

£6,53

Unit Price Incl. Tax

WASHER

D8322-9106B-000 D83229106B000

Not available

CUSHION

09320-09009-000 0932009009000

£6,18

Unit Price Incl. Tax

SPACER
SPACER (6.5X9X8.5)

09180-06262-000 0918006262000

Not available

SCREW

D2116-0620B-000

02112-0620B-000

£2,98

Unit Price Incl. Tax

BRACKET, LICENSE PLATE

35927-01D30-000 3592701D30000

Not available

CUSHION

09321-06026-000 0932106026000

£3,80

Unit Price Incl. Tax

BOLT
SCREW

D2116-0616B-000 D21160616B000

£0,34

Unit Price Incl. Tax

WASHER

D8322-9106B-000 D83229106B000

Not available

NUT

D8310-0006B-000

08319-3106B-000

£4,04

Unit Price Incl. Tax

REAR REFLECTOR
REFLEX REFLECTOR, REAR SIDE

35970-24D60-000 3597024D60000

£41,51

Unit Price Incl. Tax

BRACKET, REAR SIDE RR

35977-01D11-000 3597701D11000

£9,38

Unit Price Incl. Tax

SCREW

02142-0512B-000 021420512B000

£1,90

Unit Price Incl. Tax

NUT

08310-0005B-000 083100005B000

£2,64

Unit Price Incl. Tax

REFLECTOR ASSY REAR
REFLEX REFLECTOR ASSY, REAR

35970-07F01-000 3597007F01000

£22,12

Unit Price Incl. Tax

NUT

D8310-0005B-000 D83100005B000

Not available

BRACKET
BRACKET, REAR REFLEX REFLECTOR

35974-01D00-000 3597401D00000

£10,09

Unit Price Incl. Tax

SCREW LICENSE
SCREW

D2116-0612B-000 D21160612B000

Not available

NUT

D8310-0006B-000

08319-3106B-000

£4,04

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
