SEAT (MODEL F / G / H / J) REFER TO FIG.36A (G-4) FOR MODEL K

SEAT (MODEL K) FOR SUZUKI DR 600 1986

FAIRING (MODEL F / G / H) REFER TO FIG.37A (G-8) FOR MODEL J/K

SEAT SET (BLUE)

45100-15C50-4UZ 4510015C504UZ

Not available

SEAT SET (BLACK)

45100-15C50-58P 4510015C5058P

Not available

SEAT SET (BLUE)

45100-15C60-4UZ 4510015C604UZ

Not available

SEAT SET (BLACK)

45100-15C60-58P 4510015C6058P

Not available

SEAT SET (BLUE)

45100-15C70-4UZ 4510015C704UZ

Not available

SEAT SET
SEAT SET (BLACK)

45100-15C70-58P 4510015C7058P

Not available

SEAT SET (BLUE)

45100-15C80-4UZ 4510015C804UZ

Not available

SEAT SET (BLACK)

45100-15C80-58P 4510015C8058P

Not available

45100-15C90-4UZ
SEAT SET (BLUE)

45100-15C90-4UZ

Not available

45100-15C90-58P
SEAT SET (BLACK)

45100-15C90-58P

Not available

BRACKET, SEAT RH

45117-14A10-000 4511714A10000

Not available

BRACKET, SEAT LH

45118-14A10-000 4511814A10000

Not available

45180-14A00-4UZ
.BAND, SET GRIP (BLUE)

45180-14A00-4UZ

Not available

45180-14A50-4UZ
BAND, SEAT GRIP (BLUE)

45180-14A50-4UZ

Not available

REORDER ROBINSONS
CUSHION, UPPER

45147-23450-000 4514723450000

£3,29

Unit Price Incl. Tax

REORDER ROBINSONS
CUSHION, LOWER

45150-23450-000 4515023450000

£8,51

Unit Price Incl. Tax

SPACER

45219-23450-000 4521923450000

Not available

WASHER THRUST
WASHER, UPPER

08212-06201-000 0821206201000

£2,02

Unit Price Incl. Tax

WASHER

08322-21066-000

Not available

NUT

08316-26066-000

08316-26063-000

£2,69

Unit Price Incl. Tax

CUSHION

45149-31300-000 4514931300000

£6,11

Unit Price Incl. Tax

CUSHION

09321-08009-000 0932108009000

£4,85

Unit Price Incl. Tax

CUSHION
GROMMET, FRONT

09329-08003-000 0932908003000

Not available

CUSHION

09320-08018-000

Not available

BOLT

01107-08166-000

01500-08163-000

£1,79

Unit Price Incl. Tax

REORDER BRAN BARDSLEY
PLATE, FRONT HOOK

45120-14A00-000 4512014A00000

Not available

CUSHION

09321-08010-000 0932108010000

£5,46

Unit Price Incl. Tax

BOLT

01517-08126-000

01550-08123-000

£3,05

Unit Price Incl. Tax

CARRIER ASSY, REAR
CARRIER, REAR

46300-14A40-000 4630014A40000

Not available

FRONT BOLT

07110-08358-000

07130-08357-000

£6,41

Unit Price Incl. Tax

BOLT

07110-08257-000

07130-08257-000

£5,51

Unit Price Incl. Tax

BOLT

07110-08608-000

07130-08603-000

£6,91

Unit Price Incl. Tax

BOLT

07110-08508-000

07130-08503-000

£3,85

Unit Price Incl. Tax

TUBE, PILLION HANDLE

46322-14A40-000 4632214A40000

Not available

BOLT

01517-08167-000

01550-08167-000

£2,30

Unit Price Incl. Tax

REORDER ROBINSONS
LOCK SET, HELMET

95700-31810-000 9570031810000

Not available

BOLT

07110-06165-000

07130-06167-000

£4,85

Unit Price Incl. Tax

LABEL
LABEL, ASBESTOS WARNING

11967-82000-000 1196782000000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the SEAT (MODEL K) of your Suzuki DR 600 of DR. Let us know if you have any questions.
