LEFT SWITCH - HANDGRIP

INDICATORS (MODEL N / P) FOR SUZUKI DR 650 1993

* CATALOG PREFACE *

(1) 35601-01D00-000

LAMP ASSY, FRONT TURNSIGNAL

(1) 35601-01D10-000

INDICATOR
LAMP ASSY, FRONT TURNSIGNAL

(2) 35612-17C20-000

TURN SIGNAL LENS
LENS

(3) 35613-27A00-000

LENS GASKET
GASKET

(4) 35623-27A00-000

TAPPING SCREW

(5) 35725-40511-000

SCREW
TAPPING SCREW

(6) 35627-27A02-000

GASKET

(7) 09471-12045-000

BULB (12V 21W)
BULB (12V,12W)

(8) 35671-12E00-000

BRACKET, FRONT RH

(8) 35681-12E00-000

FRONT L.H.BRACKET
BRACKET, FRONT LH

(9) 08316-1010B-000

NUT

(10) 35603-12E00-000

LAMP ASSY, REAR TURNSIGNAL

(10) 35603-14D10-000

INDICATOR
LAMP ASSY, REAR TURNSIGNAL

(11) 35652-17C20-000

TURN SIGNAL LENS
LENS

(12) 35613-27A00-000

LENS GASKET
GASKET

(13) 35623-27A00-000

TAPPING SCREW

(14) 35725-40511-000

SCREW
TAPPING SCREW

(15) 35627-27A02-000

GASKET

(16) 09471-12045-000

BULB (12V, 21W)

(17) 08310-0010A-000

NUT

(18) 35620-12E00-000

BRACKET, REAR TURN

(19) 02142-0508A-000

SCREW CASE
.SCREW

(20) 38610-45D01-000

TURN SIGNAL RELAY
RELAY ASSY, TURNSIGNAL

(21) 09308-05022-000

GROMMET
CUSHION

	Part number	Description	Qty
# 1	35601-01D00-000 3560101D00000 3560101D00000	LAMP ASSY, FRONT TURNSIGNAL	Not available	£0,00
# 1	35601-01D10-000 3560101D10000 3560101D10000	INDICATOR LAMP ASSY, FRONT TURNSIGNAL	Not available	£0,00
# 2	35612-17C20-000 3561217C20000 3561217C20000	TURN SIGNAL LENS LENS	£17,10
# 3	35613-27A00-000 3561327A00000 3561327A00000	LENS GASKET GASKET	£7,39
# 4	35623-27A00-000 3562327A00000 3562327A00000	TAPPING SCREW	£2,40
# 5	35725-40511-000 3572540511000 3572540511000	SCREW TAPPING SCREW	£2,72
# 6	35627-27A02-000 3562727A02000 3562727A02000	GASKET	£2,72
# 7	09471-12045-000 0947112045000 0947112045000	BULB (12V 21W) BULB (12V, 12W)	£7,26
# 8	35671-12E00-000 3567112E00000 3567112E00000	BRACKET, FRONT RH	Not available	£0,00
# 8	35681-12E00-000 3568112E00000 3568112E00000	FRONT L.H.BRACKET BRACKET, FRONT LH	Not available	£0,00
# 9	08316-16105-000 08316-1010B-000 0831616105000	NUT	£3,16
# 10	35603-12E00-000 3560312E00000 3560312E00000	LAMP ASSY, REAR TURNSIGNAL	Not available	£0,00
# 10	35603-12E10-000 3560312E10000	INDICATOR LAMP ASSY, REAR TURNSIGNAL	Not available	£0,00
# 11	35652-17C20-000 3565217C20000 3565217C20000	TURN SIGNAL LENS LENS	£17,10
# 12	35613-27A00-000 3561327A00000 3561327A00000	LENS GASKET GASKET	£7,39
# 13	35623-27A00-000 3562327A00000 3562327A00000	TAPPING SCREW	£2,40
# 14	35725-40511-000 3572540511000 3572540511000	SCREW TAPPING SCREW	£2,72
# 15	35627-27A02-000 3562727A02000 3562727A02000	GASKET	£2,72
# 16	09471-12045-000 0947112045000 0947112045000	BULB (12V, 21W)	£7,26
# 17	08310-12105-000 08310-0010A-000 0831012105000	NUT	£1,69
# 18	35620-12E00-000 3562012E00000 3562012E00000	BRACKET, REAR TURN	Not available	£0,00
# 19	02142-05084-000 02142-0508A-000 0214205084000	SCREW CASE .SCREW	£1,74
# 20	38610-45D00-000 38610-45D01-000 3861045D00000	TURN SIGNAL RELAY RELAY ASSY, TURNSIGNAL	£87,35
# 21	09308-05015-000 09308-05022-000 0930805015000	GROMMET CUSHION	£3,07

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the INDICATORS (MODEL N/P) of your Suzuki DR 650 R of DR. Let us know if you have any questions.
