FRONT FENDER

REAR FENDER (MODEL N / P) FOR SUZUKI DR 650 1993

REAR FENDER (MODEL R / S)

(1) 63112-12E00-000

BODY, REAR FENDER FRONT

(2) 63113-12E20-30H

BODY, REAR FENDER REAR (WHITE)

(3) 63120-12E00-000

63120-12E00-000
REINFORCEMENT,REAR FENDER

(4) 63192-12E00-000

CUSHION, FENDER (L:125)

(5) 63193-12E00-000

CUSHION, FENDER (L:166.2)

(6) 63193-12E10-000

CUSHION, FENDER (L:149.5)

(7) 63311-03D20-000

EXTENSION,REAR F
EXTENSION, REAR FENDER

(8) 63320-03D03-000

EXTENSION REINFORCEMENT
REINFORCEMENT, EXTENSION

(9) 63411-13700-000

REORDER ROBINSONS
MUD GUARD, REAR FENDER

(10) 01570-06167-000

BOLT
BOLT,FENDER

(11) 09169-06016-000

WASHER

(12) 01500-06127-000

BOLT
BOLT,REAR

(13) 09169-06031-000

LOCK WASHER
WASHER

(14) 01570-0825A-000

BOLT
BOLT,REINF,RH

(15) 08319-31087-000

NUT

(16) 09118-08128-000

BOLT
BOLT, REINF

(17) 09116-06152-000

EXTENSION BOLT
BOLT, EXTENSION

(18) 02142-05127-000

SCREW
.SCREW, UPPER

(18) 02142-05167-000

SCREW
SCREW (5X16)

(19) 09160-05043-000

WASHER
WASHER REFER TO FIG.2A (B-6) FOR MODE REFER TO FIG.2B (B-8) FOR MODE

(20) 09160-05043-000

WASHER
WASHER REFER TO FIG.2A (B-6) FOR MODE REFER TO FIG.2B (B-8) FOR MODE

(21) 08319-21057-000

NUT

(22) 95700-03811-000

LOCK SET, HELMET

(23) 02112-0512A-000

SCREW
.SCREW, CAP

(24) 09800-21023-000

TOOL ASSY
DISCONTINUED

(25) 68319-15D10-000

LABEL, WARNING SAFETY

(26) 63116-12E01-000

REORDER ROBINSONS
DISCONTINUED

(27) 68332-14A60-000

LABEL,TIRE AIR PRESSURE DR650
LABEL, TIRE AIR PRESSURE

(28) 99011-12E50-28B

MANUAL, OWNER'S

(28) 99011-12E51-28B

MANUAL, OWNER'S

	Part number	Description	Qty
# 1	63112-12E00-000 6311212E00000 6311212E00000	BODY, REAR FENDER FRONT	Not available	£0,00
# 2	63113-12E20-30H 6311312E2030H 6311312E2030H	BODY, REAR FENDER REAR (WHITE)	Not available	£0,00
# 3	63120-12E00-000 6312012E00000 6312012E00000	63120-12E00-000 REINFORCEMENT, REAR FENDER	Not available	£0,00
# 4	63192-12E00-000 6319212E00000 6319212E00000	CUSHION, FENDER (L:125)	Not available	£0,00
# 5	63193-12E00-000 6319312E00000 6319312E00000	CUSHION, FENDER (L:166.2)	Not available	£0,00
# 6	63193-12E10-000 6319312E10000 6319312E10000	CUSHION, FENDER (L:149.5)	Not available	£0,00
# 7	63311-03D20-000 6331103D20000 6331103D20000	EXTENSION, REAR F EXTENSION, REAR FENDER	Not available	£0,00
# 8	63320-03D03-000 6332003D03000 6332003D03000	EXTENSION REINFORCEMENT REINFORCEMENT, EXTENSION	Not available	£0,00
# 9	63411-13700-000 6341113700000 6341113700000	REORDER ROBINSONS MUD GUARD, REAR FENDER	Not available	£0,00
# 10	01137-06167-000 01570-06167-000 0113706167000	BOLT BOLT, FENDER	£3,43
# 11	09169-06016-000 0916906016000 0916906016000	WASHER	£2,40
# 12	01137-06128-000 01500-06127-000 0113706128000	BOLT BOLT, REAR	£2,59
# 13	09169-06028-000 09169-06031-000 0916906028000	LOCK WASHER WASHER	£3,29
# 14	01137-08255-000 01570-0825A-000 0113708255000	BOLT BOLT, REINF, RH	£3,43
# 15	08319-31087-000 0831931087000 0831931087000	NUT	£3,10
# 16	09118-08128-000 0911808128000 0911808128000	BOLT BOLT, REINF	£2,59
# 17	09116-06152-000 0911606152000 0911606152000	EXTENSION BOLT BOLT, EXTENSION	£3,35
# 18	02142-05128-000 02142-05127-000 0214205128000	SCREW .SCREW, UPPER	£2,59
# 18	02142-05167-000 0214205167000 0214205167000	SCREW SCREW (5X16)	£1,96
# 19	09160-05017-000 09160-05043-000 0916005017000	WASHER WASHER REFER TO FIG.2A (B-6) FOR MODE REFER TO FIG.2B (B-8) FOR MODE	£3,52
# 20	09160-05017-000 09160-05043-000 0916005017000	WASHER WASHER REFER TO FIG.2A (B-6) FOR MODE REFER TO FIG.2B (B-8) FOR MODE	£3,52
# 21	08319-21057-000 0831921057000 0831921057000	NUT	£2,72
# 22	95700-03810-000 9570003810000	LOCK SET, HELMET	Not available	£0,00
# 23	02112-05125-000 0211205125000	SCREW .SCREW, CAP	Not available	£0,00
# 24	09800-20052-000 0980020052000	TOOL ASSY DISCONTINUED	Not available	£0,00
# 25	68319-15D10-000 6831915D10000 6831915D10000	LABEL, WARNING SAFETY	Not available	£0,00
# 26	63116-12E00-000 6311612E00000	REORDER ROBINSONS DISCONTINUED	Not available	£0,00
# 27	68332-14A60-000 6833214A60000 6833214A60000	LABEL, TIRE AIR PRESSURE DR650 LABEL, TIRE AIR PRESSURE	Not available	£0,00
# 28	99011-12E50-28B 9901112E5028B 9901112E5028B	MANUAL, OWNER'S	Not available	£0,00
# 28	99011-12E51-28B 9901112E5128B 9901112E5128B	MANUAL, OWNER'S	Not available	£0,00

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the REAR FENDER (MODEL N/P) of your Suzuki DR 650 S of DR. Let us know if you have any questions.
