FRAME (MODEL K1) REFER TO FIG.30A(E- 4) FOR MODEL K2/K3/K4/K5

FRAME (MODEL K2 / K3 / K4 / K5) FOR SUZUKI DR 650 2003

FOOTREST

Item numbers

FRAME COMP
FRAME (GRAY)

41100-32E10-17U 4110032E1017U

Not available

FRAME (GRAY)

41100-32E10-YU8 4110032E10YU8

Not available

FRAME (GRAY)

41100-32E30-17U 4110032E3017U

Not available

FRAME (GRAY)

41100-32E30-YU8 4110032E30YU8

Not available

FRONT PLATE
PLATE, FRONT RH

41911-32E00-000 4191132E00000

£35,84

Unit Price Incl. Tax

BOLT
BOLT, FRONT

09103-08139-000 0910308139000

£11,18

Unit Price Incl. Tax

NUT

08319-31083-000

08319-3108A-000

£3,64

Unit Price Incl. Tax

UPPER PLATE
PLATE, UPPER

41991-32E00-000 4199132E00000

£48,49

Unit Price Incl. Tax

BOLT

09103-08170-000

09103-08339-000

£5,62

Unit Price Incl. Tax

NUT

08319-31083-000

08319-3108A-000

£3,64

Unit Price Incl. Tax

REAR PLATE
PLATE, REAR RH (BLACK)

41930-32E00-019 4193032E00019

£46,91

Unit Price Incl. Tax

BOLT

01550-08203-000

01550-08207-000

£3,80

Unit Price Incl. Tax

PLUG
CAP

09250-20012-000 0925020012000

£11,78

Unit Price Incl. Tax

BRACKET
BRACKET, STOP SWITCH

43251-32E00-000 4325132E00000

£21,16

Unit Price Incl. Tax

BOLT

02162-06163-000

02162-0616B-000

£2,52

Unit Price Incl. Tax

BOLT

09103-08178-000 0910308178000

£7,39

Unit Price Incl. Tax

CHAIN ROLLER
ROLLER, CHAIN

43911-13E00-000 4391113E00000

£36,11

Unit Price Incl. Tax

SPACER

09180-08156-000 0918008156000

£10,74

Unit Price Incl. Tax

THRUST WASHER
WASHER

08211-08201-000 0821108201000

£3,40

Unit Price Incl. Tax

TOOL ASSY

09800-21034-000

Not available

BOX SPANNER
BOX SPANNER 16

09816-00100-000 0981600100000

£10,39

Unit Price Incl. Tax

TOOL HOLDER
HOLDER, TOOL

41550-32E00-000 4155032E00000

£95,51

Unit Price Incl. Tax

CAP

41552-37210-000 4155237210000

£16,07

Unit Price Incl. Tax

BOLT 6X16
BOLT

09116-06006-000 0911606006000

£2,84

Unit Price Incl. Tax

HOLDER
HOLDER, BATTERY

41540-32E00-000 4154032E00000

£113,94

Unit Price Incl. Tax

BOLT
BOLT, UPPER

09116-06167-000 0911606167000

£2,81

Unit Price Incl. Tax

COLLAR
SPACER

09169-06065-000 0916906065000

£4,84

Unit Price Incl. Tax

CUSHION(8.5X20X8)

09320-08021-000

09320-08510-000

£2,24

Unit Price Incl. Tax

BOLT
BOLT, SIDE

09116-06168-000 0911606168000

£4,15

Unit Price Incl. Tax

SPACER

09180-06038-000 0918006038000

£2,44

Unit Price Incl. Tax

CUSHION(8.5X20X8)

09320-08021-000

09320-08510-000

£2,24

Unit Price Incl. Tax

FITTING PLATE
PLATE, FITTING

41561-32E00-000 4156132E00000

£30,55

Unit Price Incl. Tax

BOLT

01550-06103-000

01550-0610B-000

£2,81

Unit Price Incl. Tax

FRAME PLUG
PLUG, FRAME PIVOT RH

43585-32E00-000 4358532E00000

£7,57

Unit Price Incl. Tax

FRAME PLUG
PLUG, FRAME PIVOT LH

43595-32E00-000 4359532E00000

£7,57

Unit Price Incl. Tax

FRAME PLUG
PLUG, FRAME BOSS

43586-32E00-000 4358632E00000

£6,90

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the FRAME (MODEL K2/K3/K4/K5) of your Suzuki of DR. Let us know if you have any questions.
