CARBURETOR FOR SUZUKI FREEWIND 650 1999

CARBURETOR FITTINGS

(1) 13573-04F00-000

SPRING

(2) 13501-04F00-000

PISTON VALVE
VALVE, PISTON

(2) 13501-04F30-000

PISTON VALVE (E22)
VALVE, PISTON

(3) 13507-04F01-000

DIAPHRAGM

(4) 13502-04F00-000

COVER ASSY
COVER ASSY, DIAPHRAGM,LH

(4) 13502-04F10-000

COVER ASSY
COVER ASSY, DIAPHRAGM,RH

(5) 09492-30013-000

PILOT AIR JET
JET, PILOT AIR (150)

(5) 09492-31001-000

JET, PILOT AIR (155)

(6) 13411-04F00-000

PLUNGER ASSY

(7) 13417-26D00-000

SPRING

(8) 13278-47091-000

O RING

(9) 13418-44080-000

PLUNGER GUIDE SCREW
HOLDER, GUIDE

(10) 13682-31210-000

STARTER VALVE CAP
CAP

(11) 09494-00907-000

NEEDLE JET
JET, NEEDLE (P-0)

(12) 13385-04F00-000

JET HOLDER
HOLDER, JET

(13) 13246-43011-000

O RING

(14) 09491-24023-000

MAIN JET (122.5)
JET, MAIN (122.5)

(14) 09491-23012-000

MAIN JET (115)
JET, MAIN (115)

(15) 13250-04F00-000

FLOAT
FLOAT ASSY

(16) 02112-0408B-000

SCREW

(17) 13602-05A10-000

SCREW

(18) 02112-05127-000

SCREW

(19) 13418-33E00-000

HOLDER

(20) 09280-05004-000

O RING

(21) 13481-04F00-000

SPRING

(22) 13394-17E60-000

E RING

(23) 13382-44030-000

JET NEEDLE WASHER
WASHER

(24) 13387-13F00-000

RING

(24) 13387-44030-000

RING

(25) 13383-04F00-000

JET NEEDLE
NEEDLE, JET (5DH23-53-3)

(25) 13383-04F40-000

NEEDLE, JET (5DH34-53-3)

(26) 13295-29901-000

O RING,PILOT AIR SCREW
O RING

(27) 13291-29900-000

WASHER

(28) 13268-48700-000

SPRING

(29) 13279-33E00-000

ADJUSTER (2.0)
SCREW, PILOT (3.0)

(30) 09492-20024-000

PILOT JET
JET, PILOT (20)

(30) 09492-22014-000

PILOT AIR JET
JET, PILOT (22.5)

(31) 13370-04F01-000

NEEDLE VALVE ASSY
VALVE ASSY, NEEDLE

(31) 13370-04F40-000

NEEDLE VALVE ASSY
VALVE ASSY, NEEDLE

(32) 13254-01010-000

FLOAT PIN
PIN

(33) 02112-04107-000

SCREW

(34) 13274-84000-000

CAP

(35) 09401-06101-000

CLIP

(36) 02112-0408B-000

SCREW

(37) 13247-02340-000

DRAIN PLUG
SCREW, DRAIN

(38) 13258-04F00-000

FL CHAMBER GASKET ASB
GASKET

(39) 13281-05A00-000

PLUG

99x

(99x) 13201-04F01-000

CARBURETOR ASSY, LH

(99x) 13201-04F10-000

CARBURETOR ASSY, LH

(99x) 13201-04F11-000

CARBURETOR ASSY, LH

(99x) 13201-04F30-000

CARBURETOR XF650U
CARBURETOR ASSY, LH

(99x) 13201-04F41-000

CARBURETOR ASSY, RH

(99x) 13202-04F01-000

CARBURETOR ASSY, RH

(99x) 13202-04F10-000

CARBURETOR ASSY, RH

(99x) 13202-04F11-000

CARBURETOR ASSY, RH

(99x) 13202-04F30-000

CARBURETOR XF650U
CARBURETOR ASSY, RH

(99x) 13202-04F41-000

CARBURETOR ASSY, LH

	Part number	Description	Qty
# 1	13573-04F00-000 1357304F00000 1357304F00000	SPRING	£22,03
# 2	13501-04F00-000 1350104F00000 1350104F00000	PISTON VALVE VALVE, PISTON	£87,30
# 2	13501-04F30-000 1350104F30000 1350104F30000	PISTON VALVE (E22) VALVE, PISTON	Not available	£0,00
# 3	13507-04F00-000 13507-04F01-000 1350704F00000	DIAPHRAGM	£37,32
# 4	13502-04F00-000 1350204F00000 1350204F00000	COVER ASSY COVER ASSY, DIAPHRAGM, LH	Not available	£0,00
# 4	13502-04F10-000 1350204F10000 1350204F10000	COVER ASSY COVER ASSY, DIAPHRAGM, RH	Not available	£0,00
# 5	09492-30013-000 0949230013000 0949230013000	PILOT AIR JET JET, PILOT AIR (150)	£25,82
# 5	09492-31001-000 0949231001000 0949231001000	JET, PILOT AIR (155)	Not available	£0,00
# 6	13411-04F00-000 1341104F00000 1341104F00000	PLUNGER ASSY	Not available	£0,00
# 7	13417-26D00-000 1341726D00000 1341726D00000	SPRING	£10,00
# 8	13278-47090-000 13278-47091-000 1327847090000	O RING	£1,79
# 9	13418-44080-000 1341844080000 1341844080000	PLUNGER GUIDE SCREW HOLDER, GUIDE	£16,07
# 10	13682-31210-000 1368231210000 1368231210000	STARTER VALVE CAP CAP	£7,39
# 11	09494-00907-000 0949400907000 0949400907000	NEEDLE JET JET, NEEDLE (P-0)	£55,21
# 12	13385-04F00-000 1338504F00000 1338504F00000	JET HOLDER HOLDER, JET	£52,03
# 13	13246-43010-000 13246-43011-000 1324643010000	O RING	£4,03
# 14	09491-23012-000 0949123012000 0949123012000	MAIN JET (115) JET, MAIN (115)	£12,49
# 14	09491-24023-000 0949124023000 0949124023000	MAIN JET (122.5) JET, MAIN (122.5)	£18,65
# 15	13250-04F00-000 1325004F00000 1325004F00000	FLOAT FLOAT ASSY	£58,20
# 16	02112-04083-000 02112-0408B-000 0211204083000	SCREW	£1,99
# 17	13602-05A10-000 1360205A10000 1360205A10000	SCREW	£6,11
# 18	02112-05127-000 0211205127000 0211205127000	SCREW	£2,59
# 19	13418-33E00-000 1341833E00000 1341833E00000	HOLDER	£9,38
# 20	09280-05004-000 0928005004000 0928005004000	O RING	£2,95
# 21	13481-04F00-000 1348104F00000 1348104F00000	SPRING	£6,11
# 22	13394-17E60-000 1339417E60000 1339417E60000	E RING	£2,84
# 23	13382-44030-000 1338244030000 1338244030000	JET NEEDLE WASHER WASHER	£6,65
# 24	13387-13F00-000 1338713F00000 1338713F00000	RING	£13,57
# 24	13387-44030-000 1338744030000 1338744030000	RING	£10,69
# 25	13383-04F00-000 1338304F00000 1338304F00000	JET NEEDLE NEEDLE, JET (5DH23-53-3)	£29,62
# 25	13383-04F40-000 1338304F40000 1338304F40000	NEEDLE, JET (5DH34-53-3)	Not available	£0,00
# 26	13295-29900-000 13295-29901-000 1329529900000	O RING, PILOT AIR SCREW O RING	£4,48
# 27	13291-29900-000 1329129900000 1329129900000	WASHER	£2,84
# 28	13268-48700-000 1326848700000 1326848700000	SPRING	£7,39
# 29	13279-33E00-000 1327933E00000 1327933E00000	ADJUSTER (2.0) SCREW, PILOT (3.0)	£16,98
# 30	09492-20024-000 0949220024000 0949220024000	PILOT JET JET, PILOT (20)	£25,82
# 30	09492-22014-000 0949222014000 0949222014000	PILOT AIR JET JET, PILOT (22.5)	£23,53
# 31	13370-04F00-000 13370-04F01-000 1337004F00000	NEEDLE VALVE ASSY VALVE ASSY, NEEDLE	£80,17
# 31	13370-04F40-000 1337004F40000 1337004F40000	NEEDLE VALVE ASSY VALVE ASSY, NEEDLE	Not available	£0,00
# 32	13254-01010-000 1325401010000 1325401010000	FLOAT PIN PIN	£6,01
# 33	02112-04107-000 0211204107000 0211204107000	SCREW	£2,59
# 34	13274-84000-000 1327484000000 1327484000000	CAP	£3,35
# 35	09401-06101-000 0940106101000 0940106101000	CLIP	£1,49
# 36	02112-04083-000 02112-0408B-000 0211204083000	SCREW	£1,99
# 37	13247-02340-000 1324702340000 1324702340000	DRAIN PLUG SCREW, DRAIN	£8,28
# 38	13258-04F00-000 1325804F00000 1325804F00000	FL CHAMBER GASKET ASB GASKET	£16,43
# 39	13281-05A00-000 1328105A00000 1328105A00000	PLUG	£7,69
# 99x	13201-04F00-000 1320104F00000	CARBURETOR ASSY, LH	Not available	£0,00
# 99x	13201-04F10-000 1320104F10000 1320104F10000	CARBURETOR ASSY, LH	Not available	£0,00
# 99x	13201-04F11-000 1320104F11000 1320104F11000	CARBURETOR ASSY, LH	Not available	£0,00
# 99x	13201-04F30-000 1320104F30000 1320104F30000	CARBURETOR XF650U CARBURETOR ASSY, LH	Not available	£0,00
# 99x	13201-04F41-000 1320104F41000 1320104F41000	CARBURETOR ASSY, RH	Not available	£0,00
# 99x	13202-04F00-000 1320204F00000	CARBURETOR ASSY, RH	Not available	£0,00
# 99x	13202-04F10-000 1320204F10000 1320204F10000	CARBURETOR ASSY, RH	Not available	£0,00
# 99x	13202-04F11-000 1320204F11000 1320204F11000	CARBURETOR ASSY, RH	Not available	£0,00
# 99x	13202-04F30-000 1320204F30000 1320204F30000	CARBURETOR XF650U CARBURETOR ASSY, RH	Not available	£0,00
# 99x	13202-04F41-000 1320204F41000 1320204F41000	CARBURETOR ASSY, LH	Not available	£0,00
