FUEL TANK (MODEL V / W / X) REFER TO FIG.30B(E-7) FOR MODEL Y/K1

FUEL TANK (MODEL Y / K1) FOR SUZUKI SAVAGE 650 2000

FUEL TANK (MODEL K2 / K3)

(1) 44100-24B80-Y7G

TANK, FUEL LS650/Y
TANK ASSY, FUEL (GREEN)

(1) 44100-24B80-33J

TANK, FUEL LS650/Y
TANK ASSY, FUEL (BLACK)

(1) 44100-24B70-Y9F

TANK ASSY, FUEL (YELLOW)

(1) 44100-24B80-33J

TANK, FUEL LS650/Y
TANK ASSY, FUEL (BLACK)

(1) 44100-24B80-Y9F

TANK ASSY, FUEL (YELLOW)

(2) 68110-24B20-BL7

TAPE SET LS650/Y
TAPE SET

(2) 68110-24B20-BL8

.TAPE SET

(2) 68110-24B20-L3U

TAPE SET LS650/Y
TAPE SET

(3) 68111-24B20-BL9

EMBLEM

(3) 68111-24B20-BM1

EMBLEM LS650/Y

(3) 68111-24B20-BM2

EMBLEM

(4) 44100-24BD0-33J

TANK ASSY,FUEL
TANK ASSY, FUEL (BLACK)

(4) 44100-24BA0-YD7

TANK ASSY, FUEL (SILVER)

(4) 44100-24BB0-33J

TANK ASSY, FUEL (BLACK)

(4) 44100-24BB0-YD7

TANK ASSY, FUEL (SILVER)

(5) 68111-24B40-YS1

EMBLEM, RH

(5) 68111-24B40-YS5

EMBLEM, RH

(6) 68121-24B40-YS1

EMBLEM, LH

(6) 68121-24B40-YS5

EMBLEM, LH

(7) 44200-24830-000

TANK CAP
CAP SET, FUEL TANK

(8) 09329-10016-000

CUSHION
CUSHION, FRONT

(8) 09329-10016-000

CUSHION
CUSHION, FRONT

(9) 44552-24B00-000

REORDER ROBINSONS
MOLDING, REAR

(10) 09320-10071-000

CUSHION(9X24X18)
CUSHION, LOWER

(11) 09180-06271-000

SPACER

(12) 09320-14013-000

CUSHION
CUSHION, UPPER

(13) 01500-0630A-000

BOLT

	Part number	Description	Qty
# 1	44100-24B70-Y7G 44100-24B80-Y7G 4410024B70Y7G	TANK, FUEL LS650/Y TANK ASSY, FUEL (GREEN)	£717,17
# 1	44100-24B70-33J 4410024B7033J	TANK, FUEL LS650/Y TANK ASSY, FUEL (BLACK)	Not available	£0,00
# 1	44100-24B70-Y9F 4410024B70Y9F 4410024B70Y9F	TANK ASSY, FUEL (YELLOW)	Not available	£0,00
# 1	44100-24B80-33J 4410024B8033J 4410024B8033J	TANK, FUEL LS650/Y TANK ASSY, FUEL (BLACK)	Not available	£0,00
# 1	44100-24B80-Y9F 4410024B80Y9F 4410024B80Y9F	TANK ASSY, FUEL (YELLOW)	Not available	£0,00
# 2	68110-24B20-BL7 6811024B20BL7 6811024B20BL7	TAPE SET LS650/Y TAPE SET	Not available	£0,00
# 2	68110-24B20-BL8 6811024B20BL8 6811024B20BL8	.TAPE SET	Not available	£0,00
# 2	68110-24B20-L3U 6811024B20L3U 6811024B20L3U	TAPE SET LS650/Y TAPE SET	Not available	£0,00
# 3	68111-24B20-BL9 6811124B20BL9 6811124B20BL9	EMBLEM	Not available	£0,00
# 3	68111-24B20-BM1 6811124B20BM1 6811124B20BM1	EMBLEM LS650/Y	Not available	£0,00
# 3	68111-24B20-BM2 6811124B20BM2 6811124B20BM2	EMBLEM	Not available	£0,00
# 4	44100-24BA0-33J 4410024BA033J	TANK ASSY, FUEL TANK ASSY, FUEL (BLACK)	Not available	£0,00
# 4	44100-24BA0-YD7 4410024BA0YD7 4410024BA0YD7	TANK ASSY, FUEL (SILVER)	Not available	£0,00
# 4	44100-24BB0-33J 4410024BB033J 4410024BB033J	TANK ASSY, FUEL (BLACK)	Not available	£0,00
# 4	44100-24BB0-YD7 4410024BB0YD7 4410024BB0YD7	TANK ASSY, FUEL (SILVER)	Not available	£0,00
# 5	68111-24B40-YS1 6811124B40YS1 6811124B40YS1	EMBLEM, RH	Not available	£0,00
# 5	68111-24B40-YS5 6811124B40YS5 6811124B40YS5	EMBLEM, RH	Not available	£0,00
# 6	68121-24B40-YS1 6812124B40YS1 6812124B40YS1	EMBLEM, LH	Not available	£0,00
# 6	68121-24B40-YS5 6812124B40YS5 6812124B40YS5	EMBLEM, LH	Not available	£0,00
# 7	44200-24830-000 4420024830000 4420024830000	TANK CAP CAP SET, FUEL TANK	£58,85
# 8	09329-10016-000 0932910016000 0932910016000	CUSHION CUSHION, FRONT	£4,99
# 9	44552-24B00-000 4455224B00000 4455224B00000	REORDER ROBINSONS MOLDING, REAR	£16,28
# 10	09320-10020-000 09320-10071-000 0932010020000	CUSHION(9X24X18) CUSHION, LOWER	£2,56
# 11	09180-06271-000 0918006271000 0918006271000	SPACER	£3,40
# 12	09320-14013-000 0932014013000 0932014013000	CUSHION CUSHION, UPPER	£3,40
# 13	01500-06303-000 01500-0630A-000 0150006303000	BOLT	£3,52
