SWINGARM (MODEL G) REFER TO FIG.66 (K-4) FOR MODEL H/J/K/L/M

SWINGARM (MODEL H / J / K / L / M) FOR SUZUKI INTRUDER 750 1987

REAR WHEEL (MODEL F / G) REFER TO FIG.69 (K-10) FOR VS750GLFH/GL

(1) 61100-38A20-019

SWINGING ARM, REAR (BLACK)

(1) 61100-38A20-14W

DISCONTINUED

(1) 61100-38A20-19A

DISCONTINUED

(1) 61100-38A20-20U

61100-38A20-20U
SWINGING ARM, REAR (MAROON)

(1) 61100-38A20-24V

SWINGING ARM, REAR (BLUE)

(1) 61100-38A20-33D

SWINGING ARM, REAR (MAROON)

(1) 61100-38A20-33J

SWINGING ARM, REAR (BLACK)

(2) 09263-22022-000

ROLLER BEARING
BEARING

(3) 61282-38E01-000

CENTRE SPACER
SPACER, CENTER

(4) 61251-32400-000

SPACER

(5) 61262-45002-000

COVER
DUST SEAL

(6) 08211-14341-000

THRUST WASHER

(7) 61211-38A00-000

SHAFT
SHAFT, PIVOT

(8) 08319-3114A-000

NUT

(9) 61222-38A01-000

CAP
CAP, RH

(10) 61232-38A00-13L

LH CAP
CAP, LH (BLACK)

(10) 61232-38A00-19A

REORDER ROBINSONS
CAP, LH (RED)

(10) 61232-38A00-YAY

COVER,RR SWGARM,L VS800
CAP, LH (BLACK)

(11) 61372-38A00-000

BOOT

(12) 09402-92306-XC0

CLAMP GSR600A/K8
CLAMP

(13) 03211-0425B-000

SCREW

(14) 64310-38A13-019

REAR TORQUE LINK
TORQUE LINK, REAR (BLACK)

(15) 09101-10037-000

BOLT
BOLT, FRONT

(16) 09160-10142-000

WASHER BALL STUD
WASHER, FRONT

(17) 09159-10059-000

NUT

(18) 09180-10137-000

SPACER,10.2X14X9.6
SPACER (10.2X14X9.60)

(19) 09111-10035-000

BOLT
BOLT, REAR

(20) 09160-10142-000

WASHER BALL STUD
WASHER

(21) 04111-1620A-000

COTTER PIN
.PIN, COTTER

(22) 09251-13002-000

CAP

(23) 09320-12501-000

CUSHION

(24) 62100-38A53-000

REAR SHOCK ASSY.
ABSORBER ASSY, REAR SHOCK

(25) 09160-10093-000

WASHER
WASHER, OUTER (10.5*24*2.3)

(26) 08316-1010B-000

NUT

(27) 09100-10247-000

SUZUKI PART
BOLT, LOWER RH

(28) 09180-10139-000

SPACER
SPACER, LOWER RH (10.2X14X20.70)

(29) 09160-10093-000

WASHER
WASHER, LOWER

(30) 08313-10107-000

NUT
NUT, LOWER

(31) 08322-0110B-000

WASHER
WASHER, LOWER RH REFER TO FIG.66 (J-4) FOR MODE

(32) 95672-24A00-000

CAP

(33) 11967-82000-000

LABEL
LABEL, ASBESTOS

	Part number	Description	Qty
# 1	61100-38A20-019 6110038A20019 6110038A20019	SWINGING ARM, REAR (BLACK)	Not available	£0,00
# 1	61100-38A20-14W 6110038A2014W 6110038A2014W	DISCONTINUED	Not available	£0,00
# 1	61100-38A20-19A 6110038A2019A 6110038A2019A	DISCONTINUED	Not available	£0,00
# 1	61100-38A20-20U 6110038A2020U 6110038A2020U	61100-38A20-20U SWINGING ARM, REAR (MAROON)	Not available	£0,00
# 1	61100-38A20-24V 6110038A2024V 6110038A2024V	SWINGING ARM, REAR (BLUE)	Not available	£0,00
# 1	61100-38A20-33D 6110038A2033D 6110038A2033D	SWINGING ARM, REAR (MAROON)	Not available	£0,00
# 1	61100-38A20-33J 6110038A2033J 6110038A2033J	SWINGING ARM, REAR (BLACK)	Not available	£0,00
# 2	09263-22022-000 0926322022000 0926322022000	ROLLER BEARING BEARING	£34,09
# 3	61282-38A00-000 61282-38E01-000 6128238A00000	CENTRE SPACER SPACER, CENTER	£28,06
# 4	61251-32400-000 6125132400000 6125132400000	SPACER	Not available	£0,00
# 5	61262-45002-000 6126245002000 6126245002000	COVER DUST SEAL	£13,36
# 6	08211-14341-000 0821114341000 0821114341000	THRUST WASHER	£4,66
# 7	61211-38A00-000 6121138A00000 6121138A00000	SHAFT SHAFT, PIVOT	Not available	£0,00
# 8	08319-31148-000 08319-3114A-000 0831931148000	NUT	£15,49
# 9	61222-38A01-000 6122238A01000 6122238A01000	CAP CAP, RH	£18,01
# 10	61232-38A00-019 61232-38A00-13L 6123238A00019	LH CAP CAP, LH (BLACK)	£63,10
# 10	61232-38A00-19A 6123238A0019A 6123238A0019A	REORDER ROBINSONS CAP, LH (RED)	Not available	£0,00
# 10	61232-38A00-33J 6123238A0033J	COVER, RR SWGARM, L VS800 CAP, LH (BLACK)	Not available	£0,00
# 11	61372-38A00-000 6137238A00000 6137238A00000	BOOT	£40,27
# 12	09402-92306-000 09402-92306-XC0 0940292306000	CLAMP GSR600A/K8 CLAMP	£9,54
# 13	03211-04255-000 03211-0425B-000 0321104255000	SCREW	£3,64
# 14	64310-38A13-019 6431038A13019 6431038A13019	REAR TORQUE LINK TORQUE LINK, REAR (BLACK)	£32,21
# 15	09101-10037-000 0910110037000 0910110037000	BOLT BOLT, FRONT	£5,51
# 16	09160-10057-000 09160-10142-000 0916010057000	WASHER BALL STUD WASHER, FRONT	£2,86
# 17	09159-10059-000 0915910059000 0915910059000	NUT	£3,71
# 18	09180-10114-000 09180-10137-000 0918010114000	SPACER, 10.2X14X9.6 SPACER (10.2X14X9.60)	£5,81
# 19	09111-10035-000 0911110035000 0911110035000	BOLT BOLT, REAR	£9,04
# 20	09160-10085-000 09160-10142-000 0916010085000	WASHER BALL STUD WASHER	£2,86
# 21	04111-16158-000 04111-1620A-000 0411116158000	COTTER PIN .PIN, COTTER	£1,80
# 22	09251-13002-000 0925113002000 0925113002000	CAP	£5,89
# 23	09320-12039-000 09320-12501-000 0932012039000	CUSHION	£10,52
# 24	62100-38A51-000 62100-38A53-000 6210038A51000	REAR SHOCK ASSY. ABSORBER ASSY, REAR SHOCK	£411,82
# 25	09160-10001-000 09160-10093-000 0916010001000	WASHER WASHER, OUTER (10.5242.3)	£2,69
# 26	08316-16106-000 08316-1010B-000 0831616106000	NUT	£3,16
# 27	09100-10247-000 0910010247000 0910010247000	SUZUKI PART BOLT, LOWER RH	£5,05
# 28	09180-10104-000 09180-10139-000 0918010104000	SPACER SPACER, LOWER RH (10.2X14X20.70)	£6,50
# 29	09160-10095-000 09160-10093-000 0916010095000	WASHER WASHER, LOWER	£2,69
# 30	08313-11107-000 08313-10107-000 0831311107000	NUT NUT, LOWER	£4,16
# 31	08322-11104-000 08322-0110B-000 0832211104000	WASHER WASHER, LOWER RH REFER TO FIG.66 (J-4) FOR MODE	£2,54
# 32	95672-24A00-000 9567224A00000 9567224A00000	CAP	£10,56
# 33	11967-82000-000 1196782000000 1196782000000	LABEL LABEL, ASBESTOS	Not available	£0,00

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
