TAIL LIGHT (MODEL M / N / P / R / S) REFER TO FIG.27A(E-15) FOR MODEL T

TAIL LIGHT(MODEL T) FOR SUZUKI DR 800 1992

WIRING HARNESS (MODEL M / N / P / R) REFER TO FIG.28A(F- 4) FOR MODEL S

Item numbers

REORDER ROBINSONS
LAMP ASSY, REAR COMBINATION

35710-31D00-000 3571031D00000

Not available

REORDER ROBINSONS
LENS

35712-31D00-000 3571231D00000

Not available

REORDER ROBINSONS
GASKET

35713-31D00-000 3571331D00000

£22,15

Unit Price Incl. Tax

SCREW

03211-04203-000

03211-04207-000

£2,04

Unit Price Incl. Tax

GASKET

35627-43010-000 3562743010000

£3,40

Unit Price Incl. Tax

BULB (12V 21/5W)

09471-12083-000 0947112083000

£8,78

Unit Price Incl. Tax

CUSHION

09320-08048-000

09320-08501-000

£2,20

Unit Price Incl. Tax

SPACER (6.1X8.0X9.5)

09180-06044-000

09180-06248-000

£2,69

Unit Price Incl. Tax

WASHER
LOCK WASHER

09160-06056-000 0916006056000

Not available

NUT

08316-10063-000

08319-31067-000

£2,69

Unit Price Incl. Tax

LAMP ASSY, LICENSE

35910-31D00-000 3591031D00000

Not available

LICENSE LAMP
LAMP ASSY, LICENSE

35910-31D10-000 3591031D10000

Not available

COVER, LENS

35917-30B00-000 3591730B00000

Not available

LENS

35912-38A20-000 3591238A20000

£29,66

Unit Price Incl. Tax

REORDER ROBINSONS
GASKET

35913-38A30-000 3591338A30000

£4,66

Unit Price Incl. Tax

BULB, 12V5W
BULB

09471-12140-000 0947112140000

£2,45

Unit Price Incl. Tax

CUSHION

35761-38A31-000 3576138A31000

Not available

SPACER

35766-38A30-000 3576638A30000

Not available

NUT

09140-04006-000 0914004006000

£7,39

Unit Price Incl. Tax

LICENSE PLATE BRKT.
BRACKET, LICENSE PLATE

35927-00A10-000 3592700A10000

£18,56

Unit Price Incl. Tax

BOLT

01550-06163-000

01550-0616B-000

£3,22

Unit Price Incl. Tax

WASHER

09160-06088-000 0916006088000

£2,12

Unit Price Incl. Tax

NUT

08310-00063-000

Not available

REFLECTOR ASSY, REAR
REFLEX REFLECTOR, REAR

35970-12D00-000 3597012D00000

Not available

NUT

08316-20053-000

08316-2005A-000

£2,70

Unit Price Incl. Tax

SPACER, REAR REFLECTOR

35977-12D00-000 3597712D00000

Not available

WASHER, REAR REFLECTOR

35997-12D00-000 3599712D00000

Not available

REFLEX REFLECTOR, FRONT SIDE
REFLEX REFLECTOR, REAR SIDE

35950-14A20-000 3595014A20000

£28,24

Unit Price Incl. Tax

NUT

08316-20053-000

08316-2005A-000

£2,70

Unit Price Incl. Tax

CUSHION LICENSE PLATE

09321-06028-000

09321-06038-000

£2,56

Unit Price Incl. Tax

CAP WIPER HOLE

09250-30010-000

Not available

EMBLEM, REAR FENDER

35995-45110-000 3599545110000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the TAIL LIGHT(MODEL T) of your Suzuki DR 800 S of DR. Let us know if you have any questions.
