FAIRING (MODEL W) COLOR : L99=1LF(BLUE),0JW(WHITE)

FAIRING (MODEL X) FOR SUZUKI TL-R 1000 1999

FAIRING (MODEL Y) COLOR : L99=1LF(BLUE),0JW(WHITE)

(1) 47110-02FC0-0JW

COVER COMP FRAME
COVER, FRAME (WHITE)

(2) 68131-33E30-K8S

FRAME COVER EMBLEM
EMBLEM

(3) 68130-02FA0-D4Z

TAPE SET RH FRAME COVER
TAPE SET, RH

(4) 68140-02FA0-D4Z

TAPE SET RH FRAME COVER
TAPE SET, LH

(5) 47110-02FD0-N0W

COVER COMP FRAME
COVER, FRAME

(5) 47110-02FD0-N0Y

COVER COMP FRAME
COVER, FRAME

(6) 68131-02F30-N1A

EMBLEM FRAME COVER (163)
EMBLEM

(6) 68131-02F30-N1B

EMBLEM

(7) 47511-02FA0-000

RR FRAME COVER HOLE CAP
CAP, RH

(8) 47521-02FA0-000

LH FRAME COVER HOLE CAP
CAP, LH

(9) 03541-0416A-000

SCREW

(9) 03541-0416A-000

SCREW

(9) 03541-0416A-000

SCREW
SCREW

(9) 03541-0416A-000

SCREW
SCREW

(10) 09136-06022-000

SCREW
SCREW, FRONT

(11) 09180-06263-000

SPACER

(12) 47161-02FA1-000

CUSHION, FRONT RH

(13) 47261-02FA1-000

CUSHION, FRONT LH

(14) 09136-06105-000

SCREW
SCREW, UPPER

(15) 09180-06286-000

SPACER

(16) 09320-10045-000

CUSHION

(17) 09139-06071-000

SCREW
SCREW, SIDE

(18) 09160-06054-000

WASHER

(19) 09180-06258-000

SPACER

(20) 94433-26B01-000

CUSHION

(21) 09409-07313-000

CLIP
CLIP, REAR

(22) 09148-05038-000

NUT(M5)
NUT

	Part number	Description	Qty
# 1	47110-02FC0-0JW 4711002FC00JW 4711002FC00JW	COVER COMP FRAME COVER, FRAME (WHITE)	Not available	£0,00
# 2	68131-33E30-K8S 6813133E30K8S 6813133E30K8S	FRAME COVER EMBLEM EMBLEM	Not available	£0,00
# 3	68130-02FA0-D4Z 6813002FA0D4Z 6813002FA0D4Z	TAPE SET RH FRAME COVER TAPE SET, RH	Not available	£0,00
# 4	68140-02FA0-D4Z 6814002FA0D4Z 6814002FA0D4Z	TAPE SET RH FRAME COVER TAPE SET, LH	Not available	£0,00
# 5	47110-02FD0-N0W 4711002FD0N0W 4711002FD0N0W	COVER COMP FRAME COVER, FRAME	Not available	£0,00
# 5	47110-02FD0-N0Y 4711002FD0N0Y 4711002FD0N0Y	COVER COMP FRAME COVER, FRAME	Not available	£0,00
# 6	68131-02F30-N1A 6813102F30N1A 6813102F30N1A	EMBLEM FRAME COVER (163) EMBLEM	Not available	£0,00
# 6	68131-02F30-N1B 6813102F30N1B 6813102F30N1B	EMBLEM	Not available	£0,00
# 7	47511-02FA0-000 4751102FA0000 4751102FA0000	RR FRAME COVER HOLE CAP CAP, RH	Not available	£0,00
# 8	47521-02FA0-000 4752102FA0000 4752102FA0000	LH FRAME COVER HOLE CAP CAP, LH	Not available	£0,00
# 9	03541-04163-000 03541-0416A-000 0354104163000	SCREW	£1,80
# 10	09136-06022-000 0913606022000 0913606022000	SCREW SCREW, FRONT	£3,71
# 11	09180-06263-000 0918006263000 0918006263000	SPACER	£2,69
# 12	47161-02FA0-000 47161-02FA1-000 4716102FA0000	CUSHION, FRONT RH	£16,97
# 13	47261-02FA0-000 47261-02FA1-000 4726102FA0000	CUSHION, FRONT LH	£23,65
# 14	09136-06105-000 0913606105000 0913606105000	SCREW SCREW, UPPER	£3,29
# 15	09180-06286-000 0918006286000 0918006286000	SPACER	£4,16
# 16	09320-10045-000 0932010045000 0932010045000	CUSHION	£6,01
# 17	09139-06071-000 0913906071000 0913906071000	SCREW SCREW, SIDE	£7,63
# 18	09160-06054-000 0916006054000 0916006054000	WASHER	£2,12
# 19	09180-06258-000 0918006258000 0918006258000	SPACER	£2,99
# 20	94433-26B00-000 94433-26B01-000 9443326B00000	CUSHION	£4,97
# 21	09409-07313-000 0940907313000 0940907313000	CLIP CLIP, REAR	£2,76
# 22	09148-05038-000 0914805038000 0914805038000	NUT(M5) NUT	£2,59

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Suzuki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
