FRONT FORK FOR SUZUKI TL-R 1000 1999

FRONT FORK for Suzuki TL-R 1000 1999

(1)  51110-02FA0-000
TUBE, INNER RH

(2)  51120-02FA0-000
TUBE, INNER LH

(3)  51121-40C00-000
BUSH
PISTON

(4)  51173-02FA0-000
SEAL, DUST

(5)  51156-14200-000
STOPPER RING
RING, SNAP

(6)  51153-02FA0-000
OIL SEAL
SEAL, OIL

(7)  51158-14200-000
WASHER

(8)  51167-02F00-000
SLIDE METAL
METAL, SLIDE

(9)  51130-02FA0-000
TUBE, OUTER

(10)  51146-02FA0-000
CYLINDER

(11)  51171-02FA0-000
SPRING, FRONT

(12)  51176-02FA0-000
SPACER

(13)  51129-27C00-000
NUT PISTON ROD
NUT

(14)  51351-02FA0-000
CAP, FORK

(15)  51147-40C00-000
BOLT

(16)  51148-40300-000
FORK CYLINDER GASKET
GASKET

(17)  01550-08457-000
BOLT
(99x)
(99x)  51103-02FA0-000
RH FRONT FORK DAMPER ASSY
DAMPER ASSY, FRONT FORK RH
(99x)  51104-02FA0-000
LH FRONT FORK DAMPER ASSY
DAMPER ASSY, FRONT FORK LH
Part number Description
# 1
TUBE, INNER RH
# 2
TUBE, INNER LH
# 3
BUSH
PISTON
# 4
SEAL, DUST
# 5
STOPPER RING
RING, SNAP
# 6
OIL SEAL
SEAL, OIL
# 7
WASHER
# 8
SLIDE METAL
METAL, SLIDE
# 9
TUBE, OUTER
# 10
CYLINDER
# 11
SPRING, FRONT
# 12
SPACER
# 13
NUT PISTON ROD
NUT
# 14
51351-02FA0-000
CAP, FORK Not available
# 15
BOLT
# 16
FORK CYLINDER GASKET
GASKET
# 17
BOLT
# 99x
RH FRONT FORK DAMPER ASSY
DAMPER ASSY, FRONT FORK RH
# 99x
LH FRONT FORK DAMPER ASSY
DAMPER ASSY, FRONT FORK LH
Here are all the parts relating to the FRONT FORK of your TL-R 1999. These are all genuine parts to assure you the best possible repair which will last.
