CAMSHAFT / VALVE

TIMING FOR SUZUKI HAYABUSA 1300 2005

THROTTLE BODY

(1) 12760-24F01-000

CHAIN COMP CAMSHAFT DRIVE
CHAIN, CAM SHAFT DRIVE (128LE)

(2) 12771-24F01-000

GUIDE, CAM CHAIN NO.1

(3) 12782-24F02-000

GUIDE, CAM CHAIN GSX1300R/L7
GUIDE, CAM CHAIN NO.2

(4) 09106-06075-000

BOLT
SCREW

(5) 12811-24F12-000

TENSIONER, CAM CHAIN

(6) 12812-26B02-000

CAM CHAIN TENSIONER BOLT
BOLT

(7) 12773-24F00-000

RETAINER CAM CHAIN GUIDE N01
RETAINER, CAM CHAIN GUIDE NO.1

(8) 02122-0612A-000

SCREW RETAINER CAM CHAIN
SCREW

(9) 12800-24F11-000

ADJUSTER ASSY TENSIONER
ADJUSTER SET, TENSIONER

(10) 12836-24F00-000

SHAFT, ADJUSTER

(11) 12837-24F10-000

GASKET

(12) 12833-05A00-000

PLUG

(13) 12831-24F10-000

SPRING MAIN
SPRING

(14) 12837-24A10-000

GASKET
GASKET, TNSN ADJUSTER

(15) 07130-0625B-000

BOLT

(16) 12835-24F00-000

HOSE, CAM CHAIN TENSIONER

(17) 12838-35F01-000

BOLT OIL HOSE UNION NO2
BOLT

(17) 12838-35F01-000

BOLT OIL HOSE UNION NO2
BOLT

(17) 12838-35F01-000

BOLT OIL HOSE UNION NO2
BOLT
BOLT OIL HOSE UNION NO2

(17) 12838-35F01-000

BOLT OIL HOSE UNION NO2
BOLT
BOLT OIL HOSE UNION NO2

(17) 12838-35F01-000

BOLT OIL HOSE UNION NO2
BOLT

(17) 12838-35F01-000

BOLT OIL HOSE UNION NO2
BOLT

(18) 09168-08016-000

GASKET

(18) 09168-08016-000

GASKET

(18) 09168-08016-000

GASKET

(18) 09168-08016-000

GASKET

(19) 12839-24F00-000

PLUG

(20) 09168-14002-000

GASKET

	Part number	Description	Qty
# 1	12760-24F00-000 12760-24F01-000 1276024F00000	CHAIN COMP CAMSHAFT DRIVE CHAIN, CAM SHAFT DRIVE (128LE)	£83,92
# 2	12771-24F00-000 12771-24F01-000 1277124F00000	GUIDE, CAM CHAIN NO.1	£51,19
# 3	12782-24F01-000 12782-24F02-000 1278224F01000	GUIDE, CAM CHAIN GSX1300R/L7 GUIDE, CAM CHAIN NO.2	£32,66
# 4	07130-06123-000 09106-06075-000 0713006123000	BOLT SCREW	£3,90
# 5	12811-24F10-000 12811-24F12-000 1281124F10000	TENSIONER, CAM CHAIN	£106,96
# 6	12812-26B02-000 1281226B02000 1281226B02000	CAM CHAIN TENSIONER BOLT BOLT	£5,56
# 7	12773-24F00-000 1277324F00000 1277324F00000	RETAINER CAM CHAIN GUIDE N01 RETAINER, CAM CHAIN GUIDE NO.1	£4,99
# 8	02122-06123-000 02122-0612A-000 0212206123000	SCREW RETAINER CAM CHAIN SCREW	£1,56
# 9	12800-24F10-000 12800-24F11-000 1280024F10000	ADJUSTER ASSY TENSIONER ADJUSTER SET, TENSIONER	£129,08
# 10	12836-24F00-000 1283624F00000 1283624F00000	SHAFT, ADJUSTER	Not available	£0,00
# 11	12837-24F10-000 1283724F10000 1283724F10000	GASKET	£3,78
# 12	12833-05A00-000 1283305A00000 1283305A00000	PLUG	£12,71
# 13	12831-24F10-000 1283124F10000 1283124F10000	SPRING MAIN SPRING	£10,26
# 14	12837-24A10-000 1283724A10000 1283724A10000	GASKET GASKET, TNSN ADJUSTER	£2,40
# 15	07130-06253-000 07130-0625B-000 0713006253000	BOLT	£4,02
# 16	12835-24F00-000 1283524F00000 1283524F00000	HOSE, CAM CHAIN TENSIONER	£106,28
# 17	12838-35F00-000 12838-35F01-000 1283835F00000	BOLT OIL HOSE UNION NO2 BOLT	£21,18
# 18	09168-08016-000 0916808016000 0916808016000	GASKET	£1,61
# 19	12839-24F00-000 1283924F00000 1283924F00000	PLUG	£15,83
# 20	09168-14002-000 0916814002000 0916814002000	GASKET	£2,84

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the TIMING of your Suzuki HAYABUSA 1300 of HAYABUSA. Let us know if you have any questions.
