WIRING HARNESS

RIGHT SWITCH - HANDGRIP (MODEL L / M,MODEL N / P / R E24) FOR SUZUKI DR 250 1992

RIGHT SWITCH - HANDGRIP (MODEL N / P / R E21)

(1) 57110-14D00-000

THROTTLE GRIP
GRIP, THROTTLE

(2) 57100-13610-000

THROTTLE CASE ASSY
CASE ASSY, THROTTLE

(3) 57122-13610-000

GUIDE PIECE
PIECE, GUIDE

(4) 57129-13601-000

COVER

(5) 02122-0410B-000

SCREW (4X10)
.SCREW

(6) 02112-0516B-000

SCREW

(7) 57421-03D00-000

BRAKE LEVER
LEVER, BRAKE

(8) 57431-05D00-000

SCREW

(9) 08319-2106A-000

NUT

(10) 57431-14511-000

LEVER PIVOT BOLT
BOLT, ADJUST

(11) 08310-0005B-000

NUT

(12) 57318-14502-000

SPRING

(13) 57460-14J02-000

SWITCH ASSY, STOP

(14) 57465-17C00-000

SCREW

(15) 57341-05D00-0NF

KNUCKLE COVER
COVER, KNUCKLE RH (BLUE)

(15) 57341-05D00-25Y

R.H. KNUCKLE COVER
COVER, KNUCKLE RH (YELLOW)

(16) 09125-05042-000

SCREW

(17) 09160-05043-000

WASHER
WASHER REFER TO FIG.2A (B-6) FOR MODE REFER TO FIG.2B (B-8) FOR MODE

(18) 09160-06130-000

WASHER

(19) 08319-2106A-000

NUT

(20) 37200-44E00-000

SWITCH ASSY,HANDLE
SWITCH ASSY, HANDLE, RH

(20) 37200-14A01-000

SWITCH ASSY, HANDLE, RH

(21) 09125-05066-000

SCREW

(22) 09407-12402-000

CLAMP
BAND

	Part number	Description	Qty
# 1	57110-14D00-000 5711014D00000 5711014D00000	THROTTLE GRIP GRIP, THROTTLE	£25,84
# 2	57100-28B00-000 57100-13610-000 5710028B00000	THROTTLE CASE ASSY CASE ASSY, THROTTLE	£36,30
# 3	57122-13600-000 57122-13610-000 5712213600000	GUIDE PIECE PIECE, GUIDE	£9,92
# 4	57129-13601-000 5712913601000 5712913601000	COVER	£21,25
# 5	02132-04105-000 02122-0410B-000 0213204105000	SCREW (4X10) .SCREW	£3,04
# 6	02112-05164-000 02112-0516B-000 0211205164000	SCREW	£2,98
# 7	57421-03D00-000 5742103D00000 5742103D00000	BRAKE LEVER LEVER, BRAKE	£14,58
# 8	57431-05D00-000 5743105D00000 5743105D00000	SCREW	£18,56
# 9	08319-21068-000 08319-2106A-000 0831921068000	NUT	£3,29
# 10	57431-14511-000 5743114511000 5743114511000	LEVER PIVOT BOLT BOLT, ADJUST	£9,61
# 11	08310-12055-000 08310-0005B-000 0831012055000	NUT	£2,64
# 12	57318-14502-000 5731814502000 5731814502000	SPRING	£7,37
# 13	57460-17C00-000 57460-14J02-000 5746017C00000	SWITCH ASSY, STOP	£30,20
# 14	57465-17C00-000 5746517C00000 5746517C00000	SCREW	£3,29
# 15	57341-05D00-0NF 5734105D000NF 5734105D000NF	KNUCKLE COVER COVER, KNUCKLE RH (BLUE)	£60,71
# 15	57341-05D00-25Y 5734105D0025Y 5734105D0025Y	R.H. KNUCKLE COVER COVER, KNUCKLE RH (YELLOW)	Not available	£0,00
# 16	09125-05042-000 0912505042000 0912505042000	SCREW	Not available	£0,00
# 17	09160-05017-000 09160-05043-000 0916005017000	WASHER WASHER REFER TO FIG.2A (B-6) FOR MODE REFER TO FIG.2B (B-8) FOR MODE	£3,52
# 18	09160-06042-000 09160-06130-000 0916006042000	WASHER	£3,29
# 19	08319-21068-000 08319-2106A-000 0831921068000	NUT	£3,29
# 20	37200-14D01-000 37200-44E00-000 3720014D01000	SWITCH ASSY, HANDLE SWITCH ASSY, HANDLE, RH	£109,24
# 20	37200-14A01-000 3720014A01000 3720014A01000	SWITCH ASSY, HANDLE, RH	Not available	£0,00
# 21	09125-05066-000 0912505066000 0912505066000	SCREW	£2,33
# 22	09407-12402-000 0940712402000 0940712402000	CLAMP BAND	£4,03

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the RIGHT SWITCH - HANDGRIP (MODEL L/M,MODEL N/P/R E24) of your Suzuki of DR. Let us know if you have any questions.
