TAIL LIGHT (E22)

TAIL LIGHT (E39) FOR SUZUKI DR 500 1984

WIRING HARNESS

(1) 35720-37471-000

LAMP UNIT, TAIL

(1) 35720-37481-000

LAMP UNIT,RR COM
LAMP UNIT, TAIL

(2) 35712-37471-000

LENS

(2) 35712-48524-000

REAR LAMP LENS
LENS

(3) 35713-48510-000

REORDER ROBINSONS
GASKET

(4) 03211-04306-000

SCREW

(5) 35627-43010-000

GASKET

(6) 02112-05257-000

.SCREW

(7) 08322-01057-000

WASHER
LOCK WASHER

(8) 08321-0105A-000

LOCK WASHER
LOCK WASHER LOCALLY)

(9) 09471-06063-000

BULB 21/5N
BULB (6V,21/5W)

(10) 35730-37480-000

BRACKET ASSY

(11) 35765-37410-000

CUSHION

(12) 35764-37410-000

CUSHION

(13) 35766-36510-000

SPACER

(14) 09160-05501-000

WASHER

(15) 35765-32410-000

CUSHION

(16) 35766-37120-000

SPACER

(17) 01500-06207-000

BOLT
BOLT, ADJUSTER

(18) 08321-01067-000

LOCK WASHER

(19) 01500-06307-000

REORDER ROBINSONS
BOLT FIG.48 (G-10) : GSX1100XD/EXD FIG.49 (G-11) : GSX1100ESD

(20) 09160-06077-000

WASHER
WASHER (6.5X20X1.2) REFER TO FIG.8A (C-6) FOR MODE REFER TO FIG.8B (C-7) FOR MODE

(21) 09169-06016-000

WASHER

(22) 08310-0006A-000

.NUT

(23) 08322-0106A-000

WASHER
.WASHER, LOWER

(24) 09308-07004-000

GROMMET

(25) 35793-37401-000

PLATE

(26) 35717-37400-000

CUSHION

(27) 35970-30910-000

REFLEX REFLECTOR
REFLEX REFLECTOR, REAR

(28) 08310-0005B-000

.NUT

(29) 08321-0105A-000

.LOCK WASHER

(30) 35974-37420-000

BRACKET

(31) 01500-0610B-000

BOLT
.BOLT 6X10

(32) 08322-0106A-000

WASHER
WASHER REFER TO FIG.40A(F-13) FOR MOD

(33) 77192-50E00-000

STOPPER
CUSHION

	Part number	Description	Qty
# 1	35720-37471-000 3572037471000 3572037471000	LAMP UNIT, TAIL	Not available	£0,00
# 1	35720-37481-000 3572037481000 3572037481000	LAMP UNIT, RR COM LAMP UNIT, TAIL	Not available	£0,00
# 2	35712-37471-000 3571237471000 3571237471000	LENS	Not available	£0,00
# 2	35712-48524-000 3571248524000 3571248524000	REAR LAMP LENS LENS	Not available	£0,00
# 3	35713-48510-000 3571348510000 3571348510000	REORDER ROBINSONS GASKET	£17,44
# 4	03211-04308-000 03211-04306-000 0321104308000	SCREW	£2,82
# 5	35627-43010-000 3562743010000 3562743010000	GASKET	£3,40
# 6	02112-05258-000 02112-05257-000 0211205258000	.SCREW	£2,33
# 7	08322-21058-000 08322-01057-000 0832221058000	WASHER LOCK WASHER	£2,44
# 8	08321-21058-000 08321-0105A-000 0832121058000	LOCK WASHER LOCK WASHER LOCALLY)	£2,44
# 9	09471-06042-000 0947106042000	BULB 21/5N BULB (6V, 21/5W)	Not available	£0,00
# 10	35730-37480-000 3573037480000 3573037480000	BRACKET ASSY	Not available	£0,00
# 11	35765-37410-000 3576537410000 3576537410000	CUSHION	Not available	£0,00
# 12	35764-37410-000 3576437410000 3576437410000	CUSHION	Not available	£0,00
# 13	35766-36510-000 3576636510000 3576636510000	SPACER	Not available	£0,00
# 14	35727-37410-000 09160-05501-000 3572737410000	WASHER	£2,41
# 15	35765-32410-000 3576532410000 3576532410000	CUSHION	Not available	£0,00
# 16	35766-37120-000 3576637120000 3576637120000	SPACER	Not available	£0,00
# 17	01107-06208-000 01500-06207-000 0110706208000	BOLT BOLT, ADJUSTER	£3,24
# 18	08321-21068-000 08321-01067-000 0832121068000	LOCK WASHER	£2,44
# 19	01107-06308-000 01500-06307-000 0110706308000	REORDER ROBINSONS BOLT FIG.48 (G-10) : GSX1100XD/EXD FIG.49 (G-11) : GSX1100ESD	£3,43
# 20	09160-06027-000 09160-06077-000 0916006027000	WASHER WASHER (6.5X20X1.2) REFER TO FIG.8A (C-6) FOR MODE REFER TO FIG.8B (C-7) FOR MODE	£2,59
# 21	09169-06016-000 0916906016000 0916906016000	WASHER	£2,40
# 22	08310-11066-000 0831011066000	.NUT	Not available	£0,00
# 23	08322-21066-000 08322-0106A-000 0832221066000	WASHER .WASHER, LOWER	£3,16
# 24	09308-07004-000 0930807004000 0930807004000	GROMMET	£3,29
# 25	35793-37401-000 3579337401000 3579337401000	PLATE	Not available	£0,00
# 26	35717-37400-000 3571737400000 3571737400000	CUSHION	Not available	£0,00
# 27	35970-30910-000 3597030910000 3597030910000	REFLEX REFLECTOR REFLEX REFLECTOR, REAR	£77,23
# 28	08310-11056-000 08310-0005B-000 0831011056000	.NUT	£2,64
# 29	08321-21056-000 08321-0105A-000 0832121056000	.LOCK WASHER	£2,44
# 30	35974-37420-000 3597437420000 3597437420000	BRACKET	Not available	£0,00
# 31	01107-06104-000 01500-0610B-000 0110706104000	BOLT .BOLT 6X10	£2,84
# 32	08322-21064-000 08322-0106A-000 0832221064000	WASHER WASHER REFER TO FIG.40A(F-13) FOR MOD	£3,16
# 33	09321-05005-000 77192-50E00-000 0932105005000	STOPPER CUSHION	£5,41

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Suzuki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the TAIL LIGHT (E39) of your Suzuki of DR. Let us know if you have any questions.
